Supply capacity: | 1000 units per month | Customization support: | Processing |
Origin: | London, UK | product name: | underground metal detector |
brand: | Original GER Detect Titan 1000 Metal | Warranty: | 3 years |
model: | Original GER Detect Titan 1000 Metal | payment terms: | Western Union, T/T, MoneyGram |
port: | Customer location |
Specification name | Specification value |
---|---|
Audio output | Piezoelectric buzzer Ø:12mm - H:9.8mm Sound pressure level 85db at 12v/10cm Frequency 4.5±0.5KHz |
Liquid crystal display (LCD) | Pulse Sensing System Screen: Graphic (LCD) 128 x 64 px - Other System Screen: Full Color Touch Screen 98mm x 57mm / 480x270 px |
length | Equipment: 380 mm - equipment with imaging and magnetic sensors 430 mm - equipment with ion sensors 565 mm - equipment with long range sensors 695 mm - equipment with coils 955 mm (closed) - equipment with coils 1345 mm (open ) |
frequency | Pulse induction system: 350Hz - other systems: max 500KHz |
data processing speed | Pulse induction system: 20 MHz - other systems: 8 MHz |
range of working temperature | 0°C to 70°C |
Working Humidity Range | up to 95 % non-condensing |
storage temperature range | - 20°C to 70°C |
Storage Humidity Range | Relative humidity up to 98% |
Operating time (54W battery) | Pulse induction system period: 10 hours - Other system period: 18 hours |
Waterproof Rating - Coil | Water resistant to (30cm) |
Waterproof Rating - Detector | Not waterproof (weatherproof only) |
Bluetooth | HC-05 Module - 2.4 GHz Radio |
Coil | Large coil: Ø=45cm - Small coil: Ø=20cm |
gross weight | 8600 grams |
equipment weight | 550 grams |
Bag weight (empty) | 4300 grams |
bag size | 670mm x 500mm x 270mm |
Battery Type | Lithium-ion rechargeable battery - external battery |
battery output voltage | Li-ion battery 10.8 VDC |
battery capacity | Lithium-ion battery 54 W |
battery runtime | Pulse induction system period: 10 hours - Other system period: 18 hours |
battery operating temperature | 0°C to 50°C |
battery storage temperature | - 5°C to 70°C |
Bag weight (empty) | 4300 grams |
Charger operating temperature | 0°C to 50°C |
Charger storage temperature | - 30°C to 80°C |
Charger input voltage | 90 → 250 VAC 50 → 60 Hz |
charger output | 12.6 VDC/1000 mA |
