Braking distance: | <5m | Maximum speed: | 28-30 km/h (adjustable) |
Origin: | Shandong Province, China | strength: | electrical |
Battery: | Large-capacity deep-cycle lead-acid battery 6V/pcs 8pcs 230Ah | size: | 4390*1500*2070mm |
fetal: | Aluminum alloy wheels, 155R12C | Charging time: | 8-10 hours |
brand: | green motor | port: | Qingdao |
Body and Roof: | injection molding | Supply capacity: | 50000 pieces per month |
scope: | 70-80 kilometers | Climbing ability: | <20% |
payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | engine: | 48V/5.5KW DC motor |
electronic system | electrical control | 60V full intelligent electric control | ||||||||||||||
Battery | 12V100AH/pc, 5pcs/60V (maintenance-free battery) | |||||||||||||||
engine | 3.5KW AC motor | |||||||||||||||
charger | Car Smart Charger | |||||||||||||||
charging time | 8--9 hours | |||||||||||||||
Charging input voltage | 220V | |||||||||||||||
Technical data | rated occupant | 6 | ||||||||||||||
length*width*height | 3900*1200*1850mm | |||||||||||||||
driven distance | 70-110 kilometers | |||||||||||||||
system voltage | 60V | |||||||||||||||
Minimum turning radius | 5.6m | |||||||||||||||
climbing ability | ≥20% | |||||||||||||||
Braking distance | ≤5m | |||||||||||||||
Maximum speed | 30km/h | |||||||||||||||
Motor Power | 3.5KW | |||||||||||||||
curb weight | 590 kg | |||||||||||||||
wheelbase | 3100 mm | |||||||||||||||
front and rear tracks | 900/1000 mm | |||||||||||||||
body system | seat material | Joint seat (leather fabric + high resilience PU seat) | ||||||||||||||
body | Steel frame+injection shell/ABS engineering plastic molded parts | |||||||||||||||
dash board | Digital display LCD instrument (including voltage, vehicle speed, mileage, light, front and rear direction signals) | |||||||||||||||
steering wheel | Car Steering Wheel | |||||||||||||||
Lights and Signals | LED combined headlights, turn signals, combined tail lights, brake lights, electric horns | |||||||||||||||
switch system | Start switch, light, advance and retreat switch | |||||||||||||||
frame | steel frame | |||||||||||||||
steering wheel | Polyurethane foam steering wheel | |||||||||||||||
Chassis system | transmission system | Continuously variable transmission system with hill climbing function | ||||||||||||||
steering system | Rack and pinion steering machine | |||||||||||||||
Braking System | Four-wheel drum hydraulic brake, double circuit hydraulic brake, parking brake device | |||||||||||||||
Front axle and suspension | The front axle is semi-floating | |||||||||||||||
rear axle and suspension | Integral rear axle + high-strength leaf spring + oil cylinder hydraulic shock absorption | |||||||||||||||
tire details | 205 / 50-10 Tubeless Tires |
