IFM All inductive sensors

Product Sensing Range Switching Frequency Output Function Output Size

IFS240 4 mm flush mount 700 Hz normally open DC PNP M12 x 1 / L = 60 mm

IGS232 8 mm flush mount 400 Hz normally open DC PNP M18 x 1 / L = 60 mm

IFT200 7 mm non-flush mount 800 Hz NO DC PNP M12 x 1 / L = 50 mm

IGS204 8 mm flush mount 400 Hz NO DC PNP M18 x 1 / L = 45 mm

IFT203 4 mm flush mount 800 Hz normally open DC PNP M12 x 1 / L = 45 mm

IFS204 4 mm Flush mount 700 Hz NO DC PNP M12 x 1 / L = 45 mm

IFS205 7 mm non-flush mount 700 Hz NO DC PNP M12 x 1 / L = 50 mm

IE5338 3 mm flush mount 800 Hz normally open DC PNP/NPN M8 x 1 / L = 40 mm

IN5225 4 mm non-flush mount 1300 Hz 2 x NO DC PNP 40 x 26 x 26 mm

IE5287 2 mm flush mount 1300 Hz normally open DC PNP M8 x 1 / L = 50 mm

IGT203 8 mm flush mount 600 Hz normally open DC PNP M18 x 1 / L = 46 mm

IM5135 40 mm non-flush mount 200 Hz complementary DC PNP 40 x 40 x 54 mm

IEC201 2 mm flush mount 100 Hz normally open DC PNP M8 x 1 / L = 50 mm

IFC204 4 mm flush mount 700 Hz NO DC PNP M12 x 1 / L = 45 mm

IEC211 3 mm quasi-flush 250 Hz NO DC PNP M8 x 1 / L = 45 mm

IEC212 5 mm non-flush mount 500 Hz NO DC PNP M8 x 1 / L = 45 mm

IET200 3 mm quasi-flush 250 Hz NO DC PNP M8 x 1 / L = 45 mm

IFS244 4 mm flush mount 700 Hz normally open DC PNP M12 x 1 / L = 45 mm

IET201 5 mm non-flush mount 500 Hz NO DC PNP M8 x 1 / L = 45 mm

IGT247 5 mm flush mount 100 Hz NO DC PNP M18 x 1 / L = 70 mm

IFC278 4 mm flush mount 100 Hz normally open DC PNP M12 x 1 / L = 40 mm

IFC279 4 mm flush mount 100 Hz normally open DC PNP M12 x 1 / L = 40 mm

IES223 3 mm flush mount 800 Hz normally open DC PNP/NPN M8 x 1 / L = 30 mm

IES217 3 mm flush mount 1500 Hz normally closed DC PNP M8 x 1 / L = 30 mm
