Feature 2: | Play original BD disk, BD ISO playback, support frame packing 3D | interface: | HDMI-in and HDMI-out |
model: | R9 Mini | Wifi: | 802.11a/b/g/n/ac dual-band wifi |
Origin: | China | Record: | Yes |
type: | high definition | port: | Shenzhen |
product: | Hard Disk Karaoke Media Player | payment terms: | L/C, T/T, Western Union, Paypal |
brand: | OEM&ODM | Decoding ability: | 1080p (Full HD) |
ROM: | PVR, PIP, USB3.0, Bluetooth V4.0, Type-C, RS232, stereo audio output, etc. | CPU: | RTD1295DD |
Connector: | hdmi | Supply capacity: | 20000 pieces per month for hard drive karaoke media player |
Memory: | Original assembly 16GB EMMC | local area network: | Ethernet/standard 10/100M/1000M |
operating system: | Android 6.0 | Packaging Details: | 1*Smart TV Box 1*Remote Control 1*HDMI Cable 1*Power Adapter (US/UK/EU/Australia) 1*User Manual |
The main function:
1.Top-notch audio performance
1).Uniway R11 isfully equippedWith ESS9038 DACsound.
The ESS9038 PRO sets a new benchmark for audio excellence with best-in-class 140 dB dynamic range in a 32-bit 8-channel DAC. ES9038PRO SABER DAC features ESS patented 32-bit HyperStreamDAC technology, which is responsible for excellent clarity and soundstage
2. Coaxial/optical/AES input
For added convenience and flexibility, the R11 can convert digital signals from cable and satellite boxes, TVs, video game consoles and other digital transmissions with coaxial and optical digital outputs as well as AES output to analog. By bypassing the low-fidelity, poor-quality DACs of traditional computer sound cards, the R11 utilizes the ES9038PRO DAC to turn any computer into a high-performance multimedia source
3).Dedicated stereo output
Stereo outputs provide XLR balanced and RCA single-ended connectors. The balanced output has a true differential signal path from the DAC to the 3-pin XLR connector. By transmitting a differential pair of signals, the balanced outputs provide better rejection of common-mode noise and improve signal quality.
4).Headphone Amplifier
For a more intimate listening experience, headphones can be connected directly to the R11'Built-in headphone amplifier. This headphone amplifier connects directly to the ESS SABER PRO DAC, offering unique performance advantages over standalone headphone amplifiers.
hardware | |
CPU | RTD1295 DD, ARM CA53X4, Mali-T820 MP3 L2 cache 1MB |
Memory | 2GB DDR4 |
storage | 16GB memory card |
interface | |
AC input | AC 110~220V input |
left/right output | Stereo audio output |
XLR output | XLR balanced stereo audio output |
Optical input | Optical input |
coaxial | coaxial input |
XLR input | XLR audio input |
RS232 | RS232 |
trigger | Trigger In/Out |
USB 3.0 | USB 3.0 host |
USB2.0 | USB 2.0 host x 2 |
TYPE-C | TYPE-C host |
wireless | 802.11 a/b/g/n, 2.4G/5.8 dual-band WIFI |
local area network | 10/100M/1000 Ethernet |
infrared | Infrared input/output |
HDMI input | HDMI2.0 input, with PVR function |
HDMI audio output | HDMI2.0 audio output only |
HDMI output | HDMI2.0 output |
Optical | light output |
coaxial | coaxial output |
composite audio/video | AV output |
headphone output jack | 6.5" headphone audio output jack |
SATA | External SATA port |
