model: | 904 | Key words: | agricultural hand tractor |
use: | farmland | Engine type: | diesel power |
product name: | agricultural tractor | operating hours: | 0-2000 |
Key words: | 4*4 rounds | Wheelbase (front/rear): | 680-770 |
Showroom location: | Peru, Kenya | Applicable industries: | farm |
Function: | agricultural equipment | type: | wheeled tractor |
Place of origin: | China | port: | Qingdao Port |
payment terms: | Western Union, D/P, MoneyGram | Year: | 2015 |
weight: | 4700kg | engine: | Deutz |
Mechanical test report: | if | Health status: | used |
Core components: | pumps, engines | Package preview: | |
Engine brand: | other | Supply capacity: | 10 groups per day |
Video outbound inspection: | if | Rated power (HP): | 120 HP |
Performance |
Maximum engine power at 2500 rpm |
75 HP*/DIN |
|
Maximum torque at 1500 rpm |
(22.7 kg rice) |
engine |
Brand/Type: |
Fiat 8045.06 |
Number of cylinders: |
3 |
|
cool down: |
water |
|
Air purifier type: |
oil bath |
|
clutch |
type: |
double board |
spread |
type: |
Gearbox with constant mesh gears. |
Number of gears: |
8 forward, 2 backward |
|
PTO |
Fully independent 540 PTO rpm |
1,967 engine speed |
Hydraulic |
maximum. Lifting capacity |
1650kg |
|
lower link |
3-point linkage Cat 1-2 manual response control. |
steering |
steering: |
Hydraulic assist, power steering. |
Brake type: |
Dry, belt, mechanical control. |
|
Front axle: |
Telescopic, inverted U-shaped, variable tread |
|
Instrumentation |
meter |
Tachometer, timer, fuel level and water temperature |
fetal |
front |
6.00-16, 7.50-16 |
rear |
14.9/13-30, 16.9/14-30, 13.6/12-36. |
|
Weight size |
gross weight |
2,070 kg |
|
overall length |
3.542mm |
|
Minimum overall width |
3,200mm |
Note: This parameter is for reference only. Different models have different data. Please contact us for specific data.
This series of products currently has advanced performance
Direct-coupled small-horsepower tractors are available in two series: two-wheel drive and four-wheel drive. It has low transmission efficiency and
It has the characteristics of small vibration, large traction force, strong adaptability and low starting, etc. It is an upgraded product of small four-wheel tractor.
Mini tractors are suitable for gardening, greenhouses, lawns, and household tasks. Mini tractors are assembled with high-quality diesel fuel
Engine, dual-stage clutch. Dual hydraulic output, hydraulic steering, popular in the international market.
