1000w to 10kw wind turbine controller 24v/48v/96v/220v/380v wind power off-grid controller wind power solar controller

Click here to contact

Product details

Brand Name:	Elleg	Output voltage:	Customizable
Input Voltage:	Customizable	application:	Hybrid Solar Systems
Packaging Details:	Standard packaging	Origin:	Jiangsu, China
Payment Terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram	Certificate:	CE
type:	MPPT, DC/AC Inverter	model:	Controller
Output power:	1000W to 10kW	Output Current:	Customizable
port:	Shanghai	Output Type:	three times
Supply Ability:	1000 pieces per week	Output frequency:	40-60 Hz
Product Name:	Hybrid Wind Solar Charge Controller Packaging and Delivery

Wind turbine controller Wind-solar hybrid controller 24V/48V 96V 220V Wind turbine controller

Rated wind power			1000W to 10kW
Nominal system voltage			24V/48V 96V 220V/380V/600V
Battery over discharge limit voltage (low)			40.8V(adjustable)
Battery over-discharge limit recovery voltage (Rlow)			46.5V(adjustable)
Battery overcharge limit voltage (full charge)			58.8V(adjustable)
Battery overcharge limit recovery voltage (RFull)			52.8V(adjustable)
Float voltage (Flot)			54.0V(adjustable)
Wind unloading speed (Rota)			500R(Adjustable)
Wind pole number (Pole)			10D (adjustable)
Wind charging range			DC (20-100) volts
Wind power start charging voltage (CutIn)			20V (adjustable)
Wind load voltage (Vmax)			100V(adjustable)
Unloading control mode			Over speed limit, over voltage limit, over current limit, PWM
Wind power charging method			MPPT and PWM
Solar charging mode			Pulse Width Modulation
Display Mode			LCD display
Display content			Battery: voltage; charging current; battery charge percentage. Wind: voltage; charging current; speed; output current; output power Solar energy: voltage; charging current. System: status; energy produced; error codes
Operating temperature and relative humidity			-20~+55℃/35~85%RH(no condensation)
Static power consumption			≤3W
Protection type			Battery: over discharge protection; over charge protection; anti-reverse connection. Wind: over speed protection, over voltage protection, over current protection.
