Specification | ||
frequency range | VHF: 136~174MHz/UHF: 400~480MHz | |
memory channel | 16 | |
Rated voltage | DC3.7V (lithium battery) | |
battery capacity | 2000mAh real battery capacity | |
channel spacing | 12.5KHz/25KHz | |
frequency sensitivity | ±2.5PPM | |
Antenna impedance | 50 ohms | |
aspect | 106*61*34mm (except antenna) | |
weight | 0.2 kg (including battery pack) | |
transmitter | ||
Output power | 2 watts | |
current | ≤1.2A | |
modulation distortion | ≤5% | |
Maximum frequency deviation | ≤5KHz/≤2.5KHz | |
CTCSS frequency deviation | 0.75KHz±50Hz | |
residual radiation | ≤7uW | |
Modulation method | 16KΩF3E/11KΩF3E | |
residual modulation | ≤-35DB | |
receiver | ||
RF sensitivity | ≤0.25uV / ≤0.3uV | |
Noiseless sensitivity | ≤0.2uV/0.25uV | |
audio distortion | < 5% | |
audio power | ≥300MW | |
Modulated receiver bandwidth | ±7KHZ | |
spurious suppression | ≥55DB | |
Intermodulation | ≥60DB | |
