Fuel: | Electric; | Gear Selection: | H, L, N,P, R; |
Brand Name: | TNN; | Max power: | 44kw(5500r/min) 60HP; |
Port: | Qingdao; | Fuel Delivery System: | Fuel Pump; |
Payment Terms: | L/C,T/T; | Model Number: | TNN 800cc UTV; |
Driveline Type: | 2WD-4WD; | Final Drive: | shaft,selectable 4x4,front differential lock; |
Engine type: | V80°-twin, Four-stroke, Liquid-cooled; | Displacement: | 800cc; |
Valve Configuration: | SOHC; | Transmission Type: | Automatic; |
Supply Ability: | 1000 Piece/Pieces per Month; | Type: | 800cc; |
Place of Origin: | Shandong China (Mainland); | Certificate: | Eec; |
Compression ratio: | 10.3:1; | Max torque: | 73N.m/5000 RPM; |
Packaging Detail: | Loading information :3units/20; 8units/40; 16 units/40HQ Packing size;2320x1490x1200mm(91.3x58.7x47.2in); |
TNN 800cc UTV 4x4 and 4x2 truck suspension cheap go karts for sale 800cc jeep
ENGINE | |
Engine type | V80°-twin, Four-stroke, Liquid-cooled |
Displacement | 800cc |
Max power | 44kw(5500r/min) 60HP |
Max torque | 73N.m/5000 RPM |
Valve Configuration | SOHC |
Compression ratio | 10.3:1 |
FUEL SYSTEM | |
Fuel Delivery System | Fuel Pump |
Choke System | N/A |
Fuel capacity | 25L(6.6 Gallon) |
DRIVETRAIN | |
Driveline Type | 2WD-4WD |
Final Drive | shaft,selectable 4x4,front differential lock |
Transmission | CVT |
Gear Selection | H, L, N,P, R |
ELECTRICAL SYSTEM | |
Forward Lights | Headlights-High & Low Beam |
Rear Lights | Brake Lights & Left/Right Signal lights |
Starting system | Electric start |
Ignition system | EFI-DELPHI |
SUSPENSION / BRAKES | |
Suspension Front/Rear | Independent double wishbone |
Brakes Front/Rear | Dual hydraulic disc, twin piston/Hydraulic Disk |
TIRES | |
Front Tread | 1260mm(49.6in) |
Rear Tread | 1230mm(48.4in) |
Front & Rear tire size | 26×9-12 / 26×11-12 |
MISC | |
Loading information | 3units/20″; 8units/40″; 16 units/40HQ |
Manufacturers Defect Warranty | 6 Months |
Top speed | 95km/h(58.9MPH) |
Dry weight | 550kgs(1212lbs) |
Shipping weight | 650kgs(1430lbs) |
Fuel consumption | 7.0L/100km |
Wheelbase | 1900mm(74.8in) |
Cargo bed load capability | 100kg |
Vehicle dimension (L×W×H) | 2860 x 1530 x 1860mm(112.6x60.2x73.2in) |
Packing size | 2320x1490x1200mm(91.3x58.7x47.2in) |
Ground clearance | 285mm(11.2in) |
Safety | Driver & Passenger Seat belts/ Driver and Passenger safety Door restraints. |
