OEM v300 SMI2246XT 2.5inch ssd 240gb

Supplier: Shenzhen Global Hightech Import & Export Co., Ltd.
Region: Guangdong, China
Contact: Ms Grace Ge
Price: $5.00 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Speed:	SSD No Need;	Type:	Internal;
Payment Terms:	T/T,Western Union,MoneyGram;	Model Number:	SATA3 SMI2246XT SSD;
Cache:	0KB;	Warranty:	3 Years warranty;
Sequential Write:	142MB/s;	Place of Origin:	Guangdong China;
Control chip:	SMI2246XT;	Testing line:	50 working lines;
ECC:	Supports BCH ECC 12/14/40 bits in 1024 bytes;	Packaging Detail:	Retail/bulk packing;
Application:	Desktop;	Advanced Functions:	NCQ, Trim, SMART,Dynamic power management;
Brand Name:	Golden memory;	Products Status:	Stock;
Type:	SSD hard drive;	Style:	SSD;
Port:	Shenzhen;	Size:	2.5";
Sequential Read:	191MB/s;	Factory website:	www.ramght.com;
Interface Type:	SATA3;	Certification:	FCC CE RoHS TUV;
Supply Ability:	10000 Piece/Pieces per Month;

OEM v300 SMI2246XT 2.5inch ssd 240gb

Product Description

Based Specification
Control chip		SMI2246XT
Interface		SATAIII
Capacity		240GB
Cache		0KB
Flash type		MLC NAND Flash
Read/Write Performance
Sequential Read		191MB/s
Sequential Write		142MB/s
4KB Random Read IOPS		70000
4KB Random Write IOPS		3000
Response Time		0.2ms
Power Consumption
Power Supply		5V+5%
Standby		0.3W
Maximum Ripple		70 mV(peak to peak)
4KB Random Write		2.5W
Reliability
Write endurance:		8 years @ 100G write/day(32G)
Read endurance:		unlimited
MTBF:		>2,000,000 hours
Data retention:		>20years @ 25°C
Data destroy support		no
Sudden power-off recovery support		yes
NCQ support		yes
Trim support		yes
Dynamic power management support		yes
SMART support		yes
ECC:		Supports BCH ECC 12/14/40 bits in 1024 bytes
Static and dynamic wear-leveling
Bad block management algorithm
Environment
Storage temperature:		-55~95 °C
Operation temperature:		-0~55°C
Humidity:		5%~95%
Vibration		15G (10 to 2000Hz)
Shock		350G at 0.5ms
Testing platform
CPU:		Intel® Core(TM) i5-2400 CPU @ 3.10GHz
Chipset:		Intel® Z68 Express Chipset
Memory:		KHX1600C9D3C1K2/4GX
OS:		Microsoft Windows 7 Professional 64-bit
AHCI Driver:		Server Express Chipset SATA AHCI Controller
BIOS Settings:		AHCI Mode
Testing software		Crystal Disk Mark 3.0;HD Tune Pro 3.5;ATTO Disk Benchmark;Iometer2008 AS_SSD Benchmark
Physical Size		100707 mm
Weight		80g
Warranty		3 years
Certification		CE,ROHS,FCC,TUV

Packaging & Shipping

1.We offer 3 years warranty for SSD.

2.About the RMA,plz send by EMS within 3KG in one package.Bulk packing is ok.

3.If buyers send by DHL,buyers will undertake the cost of customs.

4.DHL will resend the goods back to buyers if can't be clearance.

5.Buyers pay the shipping cost from buyers to us,but the RMA will free shipping Following with the next order.

Company Information

FAQ

1.Q:Why does the computer fail to detect the SSD?

A:There are two possibilities in most cases:

a) Inadequate power supply: you can try attaching to the USB connector which next to SSD into USB slot behind your computer, make sure your computer has enough power supply for the SSD. To avoid insufficient supply which will cause failure to read the SSD. please do not use USB Hub, extension cords, or other USB devices.
b)Not add new sectors: Plese check the Disk Management to confirm whetherinstalled SSD in Windows XP / Vista Win7 operating system .

2.Q: When i restart my computer. I realized that the SSD storage become largger or smaller sometimes. is it any problem with the SSD?

A: When the operating system boots, there will be job data be written in the flash disk, so there will be different larger or smaller storge condition due to the differenent condition of the flash disk. So you will find the remaining capacity be slightly larger or smaller, this is normal circumstances.

3.Q: How to use the SSD properly to well protect it?

A: Currently, the SSD average erasure feature and built-in error correction mechanism can increase the SSD lifespan. But in general, SSD lifespan depends on the how it is been used and the work environment, if mass and long time large numbers data been written or been used under high-temperature environment . which would likely to reduce the SSD lifespan.

4.Q: What is the difference between SSD and HDD?

A:Both are storage devices. but SSD with better effectiveness , especially its random access speed significantly ahead of HD. But with higher price, so more suitable for operating system installation on the practical application. The HDD with lower price and slower speed. usually been used as storage for data backup.

5.Q: How to divide SSD?
A: In Windows XP, for example, you can divide SSD through the Control Panel / System management Tools / Computer Management / Disk Management, select the installed SSD, and press the right mouse button, press add new disk to complete.

6.Q: When open the file. the file name or content becomes garbled, Why this happen?

A: It is the contact problem usually, you can re-plug and make sure SSD interfaces and computer interface contact effectively.

7.Q: What are the determinants of the SSD? seed?
A: The overall performance of SSD are decided by the hard drive interface (SATA, IDE, PCI-E, etc.), the controlling IC (program), loss of efficiency (firmware), balancing algorithm, the original Flash bandwidth and the circuit design and manufacturing processes of the PCB board.

8.Q: What does the 2 Channels 4 Channels 8 Channels 10 Channels mean?
A: It means the qty of chips of read and write data at same time. 2 channels means 2 chips do reading and writing.10-channels means 10 chips in reading and writing at the same time, depending on the management capabilities of the controlling IC. The control IC chip of INTEL 10-channel can manage 10 chips read and write data simultaneously , which can greatly enhance the speed of reading and writing data to increase work efficiency . This is not a
strict interpretation, just to assist those who do not understand the SSD works to understand the concept of the channel.

9.Q: Will the airport security perspective scanner affect SSDs?
A: The physical characteristics of SSD are similar to U disk, memory cards and flash memory in mobile phone. So do not worry. the X-rays will not affect it.

12. Q: For the IDE SSD. When open the file. it is a little slow? why this happens? How to solve it?
A: It is compatibility issues mostly, you can try to use the new version software to open the file.it can often solve the problem.
