Shineng CZC7A 35A 48V battery charger 450ah input ac 100 240v

Supplier: Shanghai Shineng Electrical Equipment Co., Ltd.
Region: Shanghai, China
Contact: Mr Daniel Gu
Price: $310.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Single gross weight:	8.5 KG;	Rated Input Power Supply:	220-240V, 50/60HZ;
Package Preview:	https://sc01.alicdn.com/kf/HLB191ewRHPpK1RjSZFFq6y5PpXaq.jpg_640x640.jpg,https://sc02.alicdn.com/kf/HLB1hAKARQvoK1RjSZPfq6xPKFXau.jpg_640x640.jpg;	Warranty:	1 Years;
Single package size:	22X40.5X14 cm;	Selling Units:	Single item;
Size:	220405140;	Charger Input Power:	2.16KW;
Certificates:	CE;	Changed Battery Range:	70-250Ah;
Brand Name:	Shineng;	Package Type:	Carton or wooden packing battery charger 48v 450ah;
Keywords:	Smarten battery charger;	Place of Origin:	Shanghai China;
Rated Charging Current:	10-30A;	Chargeable Battery Voltage:	12-48V;
Weight:	8.3KG;	Model Number:	CZC7A;

Introduction

♦ Small size, Light weight, Ease of operation multi car battery charger

♦ Combine the high frequency with technology with micro-processor in one unit to reach the best charging effect. battery charger 48v 450ah

♦ Effectively prolong the working life period of the battery battery charger 48v 450ah

♦ Automatically charging process according to the program without operator

♦ Apply to electrical pallet, electric lift, electric truck, electric tour car and various kinds of small size electric vehicles. battery charger 48v 450ah

Key Features

♦ Using IWUIa or IWUUa multi-stage charging style which is suitable for ordinary or free maintance lead acid battery.

♦ Protection function such as open circuit, over load, short circuit and over temperature.

♦ With auto-checking, time-delay start, soft-start functions.

♦ Balance charging function and automatic initial charging function.

♦ It have the function of self starting again if the power interrupted.

♦ Parameters: battery charger 48v 450ah

Type(A/V)	Rated input power supply(V)	Rate charging current(A)	Charger input power(KW)	Chargeable battery voltage(V)	Changed battery range(AH)	Size(mm)	Weight(KG)
CZC7A-20A/24V	220-240V 50/60HZ	7~20	0.7	12~24	50~160	200365140	6.6
CZC7A-30A/24V	220-240V 50/60HZ	10~30	1.1	12~24	70~240	200365140	6.6
CZC7A-35A/24V	220-240V 50/60HZ	12~35	1.3	12~24	80~280	200365140	6.6
CZC7A-50A/24V	220-240V 50/60HZ	17~50	1.8	12~24	120~400	220405140	8.3
CZC7A-30A/36V	220-240V 50/60HZ	10~30	1.6	12~36	70~240	220405140	8.3
CZC7A-30A/48V	220-240V 50/60HZ	10~30	2.2	12~48	70~240	220405140	8.3

As a factory with professional design ability, we have our own brand 'Shineng' and we have the abality to do customized commissioned works to meet special charging requirements and configuration!!
