Vacuum hopper loader for plastic Raw Material /rubber auto loaders

Supplier: Chaozhou Longhe Plastic Machinery Co., Ltd. Guangzhou Branch
Region: Guangdong, China
Contact: Ms long he
Price: $400.00 /set
Min. Order: 1 set

Click here to contact

Product details

Weight:	11kg;	Machine:	Grain vacuum automatic loader;
Condition:	New;	Dimension(LWH):	400360600 mm;
Warranty:	1 Year;	Application:	Conveying raw and granulated;
Voltage:	230v;	After-sales Service Provided:	Online support;
Brand Name:	Longhe;	Feeding capacity:	300kg/h;
Suction lift:	4m;	Absorb material:	Rubber;
Power(W):	950w;	Motor:	Carbon brush;
After-sales Service Provided:	Engineers available to service machinery overseas;	Certification:	CE/ISO9001;
Place of Origin:	Guangdong China;	Port:	Guangzhou/Shenzhen;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Type:	environment-friendly;
Lifetime:	more than 6 year;	Voltage:	230v;
Supply Ability:	200 Set/Sets per Month;	Loading:	Automatic;
Packaging Detail:	Packaged for plywood case.;

Product Description

1. This plastic raw material loading machine is applicable for conveying raw materials and granulated materials for avoiding pollution.

2. This hopper loader features microcomputer control, simple operation and easy repair, and may automatically alarm when without materials.

3. Stainless steel material chamber door for protecting the materials from pollution, independent filtering device.

4.Convenient for removing dust, adopt double elecrtic-eye switch to control the feeding action (optional), motor protective device, filter observing window.

5.Two-Material Proportional Valve is optional for mixing new material with granulated material or immediately recycling granulated material.

Technical Parameters

Model			AS-300G	AS-400G	AS-700G	AS-800G	AS-800G2
Motor power(w)	Type		Carbon Brush Type	Induction Type	Carbon Brush Type	Induction Type	Induction Type
Motor power(w)	Specification		950	750	950	750	1500
Voltage Specification			1Φ,230v,50HZ	3Φ,400v,50HZ	1Φ,230v,50HZ	3Φ,400v,50HZ	3Φ,400v,50HZ
Material Feeding Capacity(kg/h)			300	400	300	400	550
Suction Lift(M)			4	4	4	4	4
Static Air Pressure(MAX)			1500mm/HZO	1800mm/HZO	1800mm/HZO	1800mm/HZO	2400mm/HZO
Storage Tank Capacity(L)			6	10	7.5	7.5	10
Internal Diameter of Conveying Pipe(mm)			Φ38	Φ38	Φ38	Φ38	Φ38
Overall Diamension(mm)		Hopper	/	/	370x300x550	460x380x550	460x380x700
Overall Diamension(mm)		Main Unit	400x360x600	400x300x500	400x300x440	400x300x440	400x300x500
Weight(kg)			11	28	25	55	65
