Port: | shenzhen,shanghai, guangzhou; | Capacity: | 400-500KN; |
Standard: | ISO; | Type: | Anchor Bolt; |
Model Number: | R38N; | Effective Dia: | 35.7mm; |
Length: | 1-6M; | Packaging Detail: | wooden boxes or package as your requirement; |
Supply Ability: | 10000 Piece/Pieces per Month; | Payment Terms: | L/C,T/T; |
Material: | Steel; | Weight: | 6.1 kg/m; |
Effective Area: | 770mm2; | Place of Origin: | Guizhou China; |
Yield-Tensile Strength: | 520-650 N/MM2; | Diameter: | 19-38mm; |
Brand Name: | Maxdrill; |
| Description | Size | Weight | Part No. | Remark | |
(kg) | (lb) | |||||
Bit with thread R38N | Steel cross bit | R38/76 mm | 1.20 | 2.65 | 38MR31176 | Hardened cross bit for loose to medium dense conditions with small boulders |
R38/90 mm | 1.40 | 3.09 | 38MR31190 | |||
Steel arched bit | R38/76 mm | 1.20 | 2.65 | 38MR34176 | Hardened arched bit for optimized geometry for unconsolidated soil with small boulders | |
TC arched bit | R38/115 mm | 2.85 | 6.28 | 38MR342115 | TC arched bit for optimized geometry for soft to medium rock formations | |
TC cross bit | R38/76 mm | 1.25 | 2.76 | 38MR31276 | TC cross bit for soft to medium rock formations | |
R38/90 mm | 1.45 | 3.20 | 38MR31290 | |||
TC 3 cutter bit | R38/76 mm | 0.85 | 1.87 | 38MR33276 | TC insert bit for soft to medium rock formations | |
Steel button bit | R38/76 mm | 1.00 | 2.21 | 38MR30176 | Hardened button bit for unconsolidated rock with boulders | |
TC button bit | R38/76 mm | 1.00 | 2.21 | 38MR30276 | TC insert button bit for medium rock formations |
Bar R38 | Length(mm) |
Part No . |
1 m long | 38MR01 | |
2 m long | 38MR02 | |
3 m long | 38MR03 | |
4 m long | 38MR04 | |
6 m long | 38MR06 |
