CSCPOWER Refrigeration cryogenic blast freezer for seafood in china

Supplier: Fujian Century Sea Power Co., Ltd.
Region: Fujian, China
Contact: Ms Alice cscpower
Price: $3000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Warranty:	12months after commercial running;	Voltage:	380V±5%/440V±5%;
Delivery Detail:	30days;	Place of Origin:	Fujian China;
Dimension(LWH):	1600031502260;	Packaging Detail:	Standard plywood packing;
Warranty:	12months after commercial running;	Supply Ability:	30 Set/Sets per Month;
After-sales Service Provided:	Engineers available to service machinery overseas;	Certification:	ISO9001;
Power(W):	94;	Model Number:	BAF-9012;
Condition:	New;	Condition:	New;
Weight:	2300;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Voltage:	380V±5%/440V±5%;	Brand Name:	CSCPOWER;
Place of Origin:	Fujian, China (Mainland);	Type:	Plate Freezer;
Model Number:	BAF-9012;	Brand Name:	CSCPOWER;
Certification:	CE;	Port:	FUZHOU;
After-sales Service Provided:	Engineers available to service machinery overseas;	Type:	Plate Freezer;

Product Description plate freezer

cold room cold storage refrigerator freezer

Aluminum alloy contact freezer is composed of Plate evaporator, Electrol Cabinet, Hydraulic Pressure device etc. The Aluminum alloy evaporator is driven by hoist cylinder to contact with frozen foods directly and keep certain pressure. The closed touch, with frozen food forms advantages of high frozen speed, high efficiency energy-saving, sanitation and c ompact. The unit is running under normal temperature to ensure long-ter m life. Adopt contact-type heat conducting, no air flow, which is benefit to decrease foods weight loss.

The Aluminum alloy is complete stainless steel machine housing,attractive appearance,easy cleaning an operation.Electromechanical integral design,less investment is aso very conveienct on installation and operation.

Basic Data of the Machine
In-take Temp:	+15°C
Out-take Temp:	-18°C
Ambient Temp:	≤50°C
Condensing temp:	+35°C
Evap. Temp:	-35°C
Refrigerant:	R22, R404A, R717 or similar.
Freezing Time:	Fish: 2-4h/shift, (tray size: 60040080mm, 15kg/tray) Shrimp: 2-3h/shift, (tray size: 30020070mm, 2kg/tray) Codfish: 2.5h/shift, (tray size: 52031060mm, 7.5kg/tray)

Required Information for Choosing the Contact Freezer

1. Frozen product name

2.Frozen product size (L×W×H mm)

3.Frozen product unit weight (“g/pc”, or “g/box” mentioning box material)

4.Freezing capacity (ton/h)

5.Product inlet temperature and outlet temperature(°C)

6.Installation room space (L×W×H mm)

7.Required freezer type(fully contact/semi-contact/marine plate freezer)

SCOPE OF APPLICATION

The unit is widely applied in cold storage, aquatic foods, meat processing foods quick freezing industry, fish catching boat and fishery processing industry etc.

Model	Evaporation Plate				Frozen Fish		Frozen Prawn		Frozen Codfish		Dimensions (LWH) (mm)	Weight (Kg)
	Effective Layer	Spacing of Each Layer (mm)	Effective Dimension (mm)	Evaporating Area (m²)	Frrozen Capacity (Kg/Time)	Consumption(Kw)	Frrozen Capacity (Kg/Time)	Consumption(Kw)	Frrozen Capacity (Kg/Time)	Consumption(Kw)
PZ(Y)-720-B1	8	58~108	1290*1260	30	720	23	384	15	480	22	254017502350	2300
PZ(Y)-720-B2											271017501685	2400
PZ(Y)-960-B1	8	58~108	1680*1260	40	960	31	512	20	720	33	296017502350	2700
PZ(Y)-960-B2											313017501685	2800
PZ(Y)-1200-B1	10	58~108	1680*1260	49	1200	39	640	24	900	41	296017502710	3000
PZ(Y)-1200-B2											313017501945	3100
PZ(Y)-1500-B1	10	58~108	2080*1260	60	1500	48	800	30	1200	54	337017502790	3600
PZ(Y)-1500-B2											354017501945	3700
PZ(Y)-1950-B1	13	58~108	2080*1260	76	1950	63	1040	39	1560	70	337017503305	4200
PZ(Y)-1950-B2											354017502339	4200
PZ(Y)-1980-B2	11	58~108	2530*1260	78	1980	64	1056	40	—	—	378017502950	4250
PZ(Y)-2520-B2	13	58~108	2530*1260	91	2520	81	1344	51	—	—	378017503305	4900
The Products with special type can be designed and manufactured according to the requirement of the customer.The specifications are the frozen goods consumption without water.The pictures are for reference only,the styles can be made to order!
