China Hand Push Concrete Pavement Cutting Machine

Supplier: Xinxiang Tongda Road New Technology Co., Ltd.
Region: Henan, China
Contact: Ms Amanda Yang
Price: $2000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Product Name:	Road groove cutting machine;	Condition:	New;
Place of Origin:	Henan China;	Working Depth:	0-50mm;
Dimension(LWH):	1830X900X1000mm;	Supply Ability:	50 Set/Sets per Month Road groove cutting machine;
Certification:	QSMS/ ISO9001;	Weight:	260KG;
Cutter head external diameter:	122mm;	Brand Name:	TongDa;
Fuel Capacity:	24L;	Dust suction system:	Effective dust absorption can be achieved;
Working Width:	8-50mm;	Packaging Detail:	Road groove cutting machine: making wax before loading on sea ship;
UNIQUE SELLING POINT:	Low Maintenance Cost;	After-sales Service Provided:	Online support,Field installation, commissioning and training;
Power(W):	11KW;	Blade quantity:	6;
Cutter head total width:	23mm;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,Alibaba trade assurance;
Warranty:	1 year;	Safety braking system:	Adopt electronic safety control system;
Engine:	Honda GX690;	Cutter head Inner diameter:	25mm;
Applicable Industries:	Road Maintenance;	Voltage:	12V 45Ah;
Cutter head slot width:	12mm;	Port:	Qingdao/ Shanghai/ Guangzhou;

China Hand Push Concrete Pavement Cutting Machine

Product Description

Road Groove Cutting Machine description:

Road groove cutting machine primarily shared with the road sealing machine so as to widen the cracks in concrete pavement or asphalt pavement, in this way, you can repair the road cracks. This device adopted the U.S. Kohler 25 hp gasoline engine, equipped with triple heavy-duty air filter, reliable, stable performance, suitable for harsh environments.

Road groove cutting machine application:

Road groove cutting machine is mainly used for widen crack before amending seam in asphalt surface.

Road groove cutting machine features:

1. Road groove cutting machine adopts 690 double cylinder gasoline engine of Honda, which has strong power and stable performance.

2. The engine adopts triple air filter system, which minimize reduces dust impact on generator life.

3. Road groove cutting machine is equipped with electric regulating lift device, it can be adjusted cutting depth flexibly.

4. User-friendly emergency stop switch, which ensures accidents happening.

5. Reasonable crack pointer avoid working fault.

6. Alloy towing base plate can be adjusted according to workers stature.

Technical parameter

Model		TDK-300	TDC300
cutting width		8-50mm	12-20mm
cutting depth		0-50mm
Engine		Honda GX690
Engine power		11KW	18KW
Safety braking system		Adopt electronic safety control system
Dust suction system		Effective dust absorption can be achieved
Fuel Capacity		24L	18L
Blade quantity		6
Machine weight		260KG
Boundary dimension		1830X900X1000mm	900X780X1480mm
Accumulator		12V 45Ah
Cutterhead	External diameter	122mm
	Inner diameter	25mm
	Slot width	12mm
	Total width	23mm
