Mn-Zn High Frequency Transformer Switching power flyback transformer EE13

Supplier: Shaanxi Fullstar Electronics Co., Ltd.
Region: Shaanxi, China
Contact: Ms Sophie Xu
Price: $0.05 / >=100 pieces
Min. Order: 100 pieces

Click here to contact

Product details

Supply Ability:	1000000000 Piece/Pieces per Day;	Model Number:	PQ TYPE;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Shape:	PQ;
Shipping Term:	DHL Fedex TNT EMS UPS;	Port:	Xi'an,Shanghai,Ningbo,Shenzhen,Beijing;
Certification:	RoHs CE RSO9001;	Place of Origin:	Shaanxi China (Mainland);
Quality:	100% Tested;	Coil Number:	Autotransformer;
Application:	Industrial Application;	Product name:	High- Frequency Transformer;
Brand Name:	Fullstar;	Transformer Speed:	10/100/1000/10G Base-TX;
Coil Structure:	Toroidal;	Packaging Detail:	In Carton----China manufacture Ferrite Core High-power Transformer Soft Magnetic Mn-Zn Ferrite Core PQ core;
Phase:	Single;	Packing:	Carton;
Input current:	5-120A current transformer;	Material:	Ferrite Core;
Usage:	High Frequency;

Product Description

Mn-Zn High Frequency Transformer Switching power flyback transformer EE13

Transformer is to transform ac voltage, current and impedance of the device, when the primary zhongtong have alternating current coil, iron core (or core) to produce ac magnetic flux, induced in the secondary coil voltage (or current). A transformer consists of an iron core (or a magnet) and a coil. The coil has two or more windings, of which the winding is called a primary coil and the rest is called a secondary coil.

Product name	Mn-Zn High Frequency Transformer Switching power flyback transformer EE13
Brand name	Fullstar
Model Number	PQ TYPE
Usage	High Frequency
Coil Structure	Toroidal
Phase	Single
Material	core, wire, bobbin
Certification	ISO9001:2008
Package	Carton
Shipping Term	DHL Fedex TNT EMS UPS
Product features	1.High efficiency, high quality materials 2.Low working temperature and long service life. 3.Good insulation and high resistance to electric power. 4.Good anti-interference performance and high reliability. 5. Low energy consumption and high dc superposition.

PART NO.	PINS	Dimension in mm
PART NO.	PINS	A	B	C+/-0.5	D+/-0.5	E+/-0.5	F	TYPE
XP-EE-8.3	6	8	8	6	4	2.5	8.3	V
XP-EE-10	8	11.5	10.2	8	4	2.5	10.2	V
XP-EE-13	10	12	12.5	8.5	4	2.5	13	V
XP-EE16-1	6	14.8	13.3	9	4	3	16	V
XP-EE16-2	10	15.4	13	10.5	4	3.2	17.1	V
XP-EE16	10	28.5	16	12.3	4	4.3	21.9	V
XP-EE19-1	8	17.6	16	10	4	5	19	V
XP-EE19-2	10	17.2	16.2	13	4	3.9	20	V
XP-EE25-1	6	20	18.2	12.5	4	6.3	25.2	V
XP-EE25-2	8	21.7	17.5	12.6	4	5	25.2	H
Customized designs are available.

Electrical performance:

1. Operating frequency: 20kHz-500KHz
2. Output power: 30 to 80 W
3. Operating temperature:-40 ℃ to +125 ℃
4. Storage temperature:-25 ℃ to +85 ℃
