Max velocity: | 8m/min; | Certification: | CE; |
drive system Z axis: | Ball screw; | After-sales Service Provided: | Field maintenance and repair service; |
Single package size: | 100X100X100 cm; | Applicable Industries: | Manufacturing Plant,Advertising Company; |
Engraving Speed: | 2.2KW; | XYZ repositioning positioning accury: | ±0.01mm; |
Operating system: | Ncstudio/DSP/Mach3; | Single gross weight: | 200 KG; |
Dimensions: | 600*900mm; | Condition: | New; |
Brand Name: | Hopetool; | working area: | 600*900; |
Feeding Height: | 3,4,6mm; | work mode: | Stepper; |
drive system X-Y axis: | Ball screw; | Warranty: | 2 Years; |
Main Axle Rotational Speed: | 0-24000rmp; | Milling Cutter Diameter: | 3,4,6mm; |
Weight: | 220KG; | Application: | metal,stone; |
Rated Power: | 8m/min; | Selling Units: | Single item; |
XYZ travel positioning accuracy: | ±0.01mm; | Place of Origin: | Shandong China; |
Characteristic
1.high accuracy ball bearing guide screw of taiwan,minimize the slit.
2.imported linear rail,self lubricating glide.
3.our routers have the features of recarving after stop and the power failure may be restored.
4.unique preservation way of the zero point.
5.use for long time and no distortion.
6.this type is suitable for engraving Metal,Stone,wood etc.
Performance parameter
number | Description | parameter |
1 | XYZ working area | 600*900*100mm |
2 | Table size | 740*1120mm |
3 | XYZ travel positioning accuracy | ±0.01mm |
4 | XYZ repositioning positioning accury | ±0.01mm |
5 | Gantry | cast-aluminium |
6 | lathe structure | casting iron |
7 | drive system X-Y axis | Ball screw |
8 | drive system Z axis | Ball screw |
9 | Spindle power | 2.2KW |
10 | Max velocity | 8m/min |
11 | Max working speed | 6m/min |
12 | Spindle speed | 0-24000rmp |
13 | work mode | Stepper |
14 | Working voltage | AC220V |
15 | Command language | G code |
16 | Interface | USB |
17 | Operating system | DSP/Mach3/Ncstudio |
18 | Flash memory | 128 |
19 | X-Y resolution | 0.025mm |
20 | Software environment | Wentai type3 artcam |
21 | Running environment | Temperature:0-45°C |
22 | Packing size | 1550*1140*900mm |
23 | Net weight | 165kg |
24 | Gross weight | 200kg |
Training and Use
1. We will supply with the machine operation manual in English version for installing and operation.
2.Customer can come to our factory training .
3.Our engineer can go to customer's factory training.
Warranty and After service
1. Our warranty is 2 years counting from the date when the Machine arrives at the port of
destination.
2. We will supply after service 24 hours,customer can contact us any time.
3.When some problems can’t be solved by customers, our engineer can go to door to help.
Questions and answer:
Q1.how to get the most suitable machine and best price
please tell the material you want to working on ?
How to working on it ? Engraving ? Cutting ? Or other ?
What’s the MAX size of these material ?( length ? Width ? Thickness ?)
Q2.What is the payment?
The payment is 30% or 50% T/T or Alibaba trade assurance in advance, balance after machine finished.
Q3.What is the producing time after order?
The proucing time is about 10-20 days depend on different machines.
Q4.If we don't know how to use the machine,can you teach us?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if
you are busy ,we will have the special engineer to your country,but you need to bear some fee,like
tickets and hotel and meal.
Q5.How about your after-sales service?
we offer you 24 hours service phone,skype or whatsapp, our engineer also can go to door install or training.
Q6. Quality Control:
The whole production procedure will be under regular inspection and strict quality control. The
complete machine will be tested to make sure they can work very well before being out of factory.
The testing video and pictures will be available before delivery.
