Best price food grade widely used shipping iso tank manufacturers

Product details
External Dimensions(l x W x H)(mm):20' X 8' X8'6'';Supply Ability:6000 Unit/Units per Year the price depends on the real required specification;
Capacity:26,000 Litres +/- 1%;Capacity:10,900 litre to 26000 litre;
Packaging Detail:Nude packing for Best price food grade widely used shipping iso tank manufacturers.;Type:Tank Container;
Frame Dimensions:20' x 8' x 8'6";Product Name:Best price food grade widely used shipping iso tank manufacturers;
Delivery Detail:3 Months after receiving your down payment;Place of Origin:Jiangsu China (Mainland);
Certification:ISO9001;Inspection Agency:LR or BV;
Frame Material:GB/T 1591-Q345D;Design Approvals:IMDG T11, CFR 49, ADR/RID, CSC, TC, TIR, ISO, UIC, US DOT;
Payment Terms:L/C,T/T;Max Payload:32,230 kgs;
Brand Name:Nttank;Port:Nantong or Shanghai port;
Design Temp:-40C to +130C;Length (feet):20';
Internal Dimensions(l x W x H)(mm):20(L) x 8(W) x 86(H);M.G.W.:36,000 kg;
Frame to Shell:304 stainless steel;Model Number:FG iso tank manufacturers;
Product Description



Best price food grade widely used shipping iso tank manufacturers





Detail:











Specification:

Tank Type

20’ ISO full frame collar tank, Type UN Portable Tank T11,

insulated, steam heated, for food grade cargo

Frame Dimensions

20’ x 8’ x 8’6”

Capacity

26,000 Litres +/- 1%

M.G.W.

36,000 kg

Tare (est.)

3,800 kgs ±3%

Max Payload

32,230 kgs

Working Pressure

4 Bar

Test Pressure

6 Bar

Design Temp

-40°C to +130°C

Vessel Material

SANS 50028-7 WNr 1.4402/1.4404 (C<0.03%), 316L stainless steel equivalent

Shell: Cold Rolled 2B finish

Dished ends: Internally polished to 1.2 Micron CLA

Shell Thickness

Calculated thickness: 4.18mm min.

Corrosion allowance: 0.2mm

Manufacturing thickness: 4.4mm min.

Ends Thickness

Calculated thickness: 4.4 mm Minimum after forming

Corrosion allowance: 0.2mm

Manufacturing allowance: 4.6mm Minimum after forming.

External pressure

0.41 Bar

Corner castings

SO 1161 - 8 off

Frame Material

GB/T 1591-Q345D

Frame to Shell

304 stainless steel

Corner castings

ISO 1161 - 8 off

Vessel Design Code

ASME VIII Div 1

Radiography

Shell

Ends

ASME Spot

ASME Full

Inspection Agency

LR or BV

Cargo carried

For food grade cargo

Design Approvals

IMDG T11, CFR 49, ADR/RID, CSC, TC, TIR, ISO, UIC, US DOT
