Automatic A4 Paper Cutting and Packaging Machine

Supplier: Ruian Dongteng Machinery Co., Ltd.
Region: Zhejiang, China
Contact: Mr Lin H
Price: $50000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Supply Ability:	1 Set/Sets per Month;	Voltage:	220V AC/ 22V DC;
Place of Origin:	Zhejiang China;	Certification:	CE Certificate;
Computerized:	Yes;	Port:	Ningbo or Shanghai;
After-sales Service Provided:	Engineers available to service machinery overseas;	Payment Terms:	L/C,T/T;
Weight:	10000 kg;	Power(W):	20-22 kw;
Brand Name:	DongTeng;	Type:	Paper Cutting Machine;
Packaging Detail:	The machine is wrapped by thin film in the wooden containers.;	Warranty:	1 Year;
Dimension(LWH):	7 x 7 x 2.1 m;	Condition:	New;

Brief Description

A4 Copy Paper Cut Size Sheeting & Wrapping Machine (DTCP-A4-5) is the best choice for the small capacity production or for the starter. The machine is featured by :
---high speed: max.300m/min
---high production capacity:5—6 reams/min
---small space required: 7m x 7m
---easy operation
---less labor power: only 3 men required
---low cost

Highlight Spot

Hydraulic system is adopted to pick up the paper reels. Magnetic Power Brake is adopted to control the tension, keeping the machine run.

Slitting Blade is made in German,featured by accurate positioning, easy adjustment, long service time and less grinding.

Cross Sheeting blade is made in German, TCT.Synchro type, shear cutting method.

Conveying belt is from Switzerland The German vibration motor is

Rapplon.Timing Belt is from adopted, low noise.

German Continental.

Components of SIMENS OMRON,

SCHNEIDER, YASKAWA are adopted,

keep smooth running for long time.

Technical Parameters

Model	DTCP-A4-10E
Unwinding Paper Reels	2
Number of Pockets	2
Recommended Width of Paper Roll (mm)	845-860
Net Cutting Width (mm)	840
Diameter of Paper Roll (mm)	400-1200
Diameter of Core Chuck	3”(76.2mm)
Paper GSM (gsm)	60-100
Length of Sheeted Paper (mm)	297
Paper Quantity per Ream (pcs/ream)	250-500
Ream Height (mm)	30-60
Working Speed of Paper Feeding	250--300m/min
Working Cutting Speed (cutting/min)	840
Ream Discharging speed (reams/min)	10-12
Max. Knife Loading (gsm)	400 (4×100)
Compressed Air (Mpa)	0.6-0.8
Compressed Air Consumption (NL/min)	300
Overwrapping Paper Size (mm) (LxW)	386 x 550-560
Paper Cutting Accuracy (mm)	Length: ±0.2
	Width: ±0.1
	Squareness:±0.15
Requirement for paper Reel	1.Stable Speed 2. Paper roll with no breakage 3. Qualified paper
Transmission	AC Frequency conversion, stepless speed regulating
Main power source	380v/50Hz 3phase 4 wires
Control voltage	220V AC/22V DC
Total Power (kw)	20-22
Gluing Heating Power (kw)	2.25
Overall Dimension (m) (LxWx H)	7 x 7 x 2.1
Weight (T)	10
