Usage: | Pipe Clamp; | Certification: | SGS,ISO,ROSH; |
Material: | W2; | Port: | Ningbo; |
Product Type: | American Type Hose clamp; | Material: | Stainless Steel; |
Standard or Nonstandard: | Standard; | Band thickness: | 0.0235"&0.0275"; |
Brand Name: | WODAFENG; | Package: | 100pieces/bag,10bags/carton; |
Payment Terms: | L/C,D/P,T/T,Western Union; | Product name: | extra large hose clamps; |
Packaging Detail: | 100pieces/bag,10bags/carton for extra large extra large hose clampss; | Label: | accept customized; |
Model Number: | Bandwidth 1/2" 12.7mm; | Production Capacity: | ,2500,000 pcs per month; |
Available Size: | 3/4" 11-20mm; | Supply Ability: | 3000000 Piece/Pieces per Month extra large hose clamps; |
Usage: | Pipe Clamp; | Place of Origin: | Zhejiang China; |
Structure: | Spring Clamp; |
American type Flexible clamping range key duct clamp
SAE Size | Range in inch | Range in mm | SAE Size | Range in inch | Range in mm |
SAE 5 | 3/4" | 11-20mm | SAE44 | 3-1/4" | 59-82mm |
SAE 6 | 7/8" | 13-23mm | SAE48 | 3-1/2" | 65-89mm |
SAE 8 | 1" | 16-25mm | SAE52 | 3-3/4" | 72-95mm |
SAE10 | 1-1/16" | 14-27mm | SAE56 | 3"-4" | 78-101mm |
SAE12 | 1-1/4" | 18-32mm | SAE60 | 4-1/4" | 84-108mm |
SAE16 | 1-1/2" | 21-38mm | SAE64 | 4-1/2" | 91-114mm |
SAE20 | 1-3/4" | 21-44mm | SAE72 | 5" | 103-127mm |
SAE24 | 2" | 27-51mm | SAE80 | 5-1/2" | 118-140mm |
SAE28 | 2-1/4" | 33-57mm | SAE88 | 6" | 130-152mm |
SAE32 | 2-1/2" | 40-63mm | SAE96 | 6-1/2" | 143-165mm |
SAE36 | 2-3/4" | 46-70mm | SAE104 | 7" | 155-178mm |
SAE40 | 3" | 52-76mm |
Material Code | Explanations |
W1 | Band,housing&screw,all zinc plated. |
W2 | Band and housing with all stianless steel(201ss,304ss),zinc plated screw. |
W3 | Band and housing with all stianless steel 304,nickel plated screw. |
W4 | Band,housing&screw,all stainless steel 304 |
W5 | Band,housing&screw,all stainless steel 316 |
Ningbo Wodafeng Hardware Technology Co., Ltd is a professional manufacturer and exporter of extra large hose clamps, hardware accessories, and different types of aluminum flashlight, headlamp etc. We are located in Ningbo China .Where is only 60 kilometers away from Ningbo sea port and airport. 2 hours by car from Shanghai air port.
Our main products include: American Type Hose Clamp, Quick Release Hose Clamp, German Type Hose Clamp, British Type Hose Clamp, Double Wire Hose Clamp, High Torque Worm Drive Hose Clamp, all types of lighting flashlight products etc. They are widely used in agriculture, auto parts accessories, construction industry, and communication equipments fields.
Our factory can do OEM/ODM, a custom-made order and small quantity order is acceptable. We are fully committed to providing our clients with high quality products, prompt delivery and professional services.
Responsibility is quality assurance; quality is the life of a brand. If you are interested in any of our products or would like to discuss a customized order, please feel free to contact us. We are looking forward to forming successful business relationships with clients all over the world in the near future.
Welcomes join us sincerely!
Q1.Are you factory or trading company?
A:we are professional maufacturer and exporter of all kinds of hardware products .Main included hardware accessories,higher power rechargeble aluminum falshlight/headlamp etc..
Q2.Can you supply samples in free?
A:Yes,we supply samples to our clients in free,but the clients must bear the courier fee by themselves.
Q3.How about your delivery time?
A:Samples delivery time about 7-10days.
Large cargo we used the restocking-sell method,if the warehouse have,we may delivery it in several days,or 25-50 days after receiving the deposit. It depends on the quantity ordered.
Q4.What is your payment terms?
A:Generally we accept TT:30% at deposit ,70% before delivery;L/C at sight of total amount.
Q5.Where is your factory located ? Is it convenient to visit?
A:Our factory located in Ditang Town Yuyao city Zhejiang province,China,It's only 1 hours from Ningbo Lishe Airport;2 hours from Shanghai Pudong international Airport.
Both of them have Bullet train to our city,which is very convenient for you to come to us.
