factory supply good selling high speed bowl cutter

Product details
Bowl volume:200L;Name:factory supply good selling high speed bowl cutter;
Delivery Detail:0 days after payment;Single gross weight:3,800 KG;
Place of Origin:Hebei China (Mainland);Cutting speed:750/1500/3000/4500rpm;
Single volume:10 cm;Condition:New;
Weight:4100kg;Bowl Rotation Speed:8/12rpm;
Capacity:125kg/time;After-sales Service Provided:Engineers available to service machinery overseas;
Material:SUS304 Stainless steel;Power(W):89Kw;
Selling Units:Single item;Certification:ISO9001,CE.;
Dimension(L*W*H):3250*2300*2100mm;Voltage:380V;
Package Type:wooden case;Warranty:Within 2 years.;
Brand Name:HELPED;Rotation speed of output:75/30-75rpm;

factory supply good selling high speed bowl cutter

Vacuum bowl cutter ZKZB-200



O/A Service

O/A is Open Account.We can supply O/A,L/C 30 or 60 days.





Product Description



Cutting and mixing machine is important equipment in meat processing industry.It can cut meat into emulsified shape in high-speed cutting knives and mix up other additives into meat sufficiently.



Cut,mix and emusify meat material under vacuum state,prevented protein and fat being oxygenized and damaged,maximumly

maintained the original color,scent and taste.Density and flexibility of products being enhanced by cutting.increased productivity,

reduced air bubble,enhanced flexibility,Featured good emulsification effect and ensured best quality.



1>Adopt good quality stainless steel.Knives are made of imported material.Or imported knives can be another option.



2>Maximum speed 4500 rpm;



3>Main shaft bearing use large size of import being use large size of import bearing;Bearing seal adopt 4 modes,avoid bearing

 failure;



4>Bowl adopt casting stainless steel,with anti-overflow pan edge.Avoid flash overflow;



5>Electric appliance case install separately,good air tightness,and waterproof and moisture protection;with temperature display;

Self-dump function.



6>Key parts produced by advanced machine processing center.Ensure the precision of process;



7>Carefully designed with excellent moving balance.Low noises.



8>Also suitable for fish,fruit,vegetable,and nut fruits processing.



Type

Bowl

Volume(L)

Capacity(kg/time)

Cutting Speed(rpm)

Bowl

Rotation

Speed(rpm)

Rotation

speed of

output(rpm)

Power(kw)

Weight(kg)

External Dimension(mm)

ZB200

200

125

Normal 750/1500/3000

8/12

75/30-75

42

4200

3500*2100*2200

GZB200

 200

 125

High speed750*1500*3000*4500

 8/12

 75/30-75

62

 4200

3500*2100*2200

KZB200(Vacuum)

200

 125

High speed vacuum750*1500*3000*4500

 8/12

 75/30-75

89

4500

3250*2300*2100

ZBK200Ⅱ(Vacuum)

 200

125

High speed vacuum750*1500*3000*4500

4/8/12

30-100

92

4500

3450*2500*2100



Our Services

Warranty period: Two years.(If the machine has quick-wear part within two years,we can supply you the quick-wear part for free.)

Meanwhile,we have best after-sales service and we can apoint our Engineers to your factory to Installation debugging.

After-sales Service
1.If you need, our technicians will go to your place to help you install and adjust the machine.
2.Train your workers how to use and maintain the machine in daily use.
3.Any parts you need will be sent directly from us.
