Certification: | ISO; | Brand Name: | SMAC; |
Precision: | Precision; | Place of Origin: | Jiangsu China; |
Payment Terms: | L/C,D/P,T/T; | Applicable Industries: | Garment Shops,Building Material Shops,Manufacturing Plant,Food Shop,Energy & Mining,Advertising Company; |
Local Service Location: | Egypt,Canada,Algeria; | Showroom Location: | Canada; |
Supply Ability: | 100 Set/Sets per Month; | After Warranty Service: | Video technical support,Online support,Spare parts,Field maintenance and repair service; |
Processing: | Metal; | Condition: | New; |
Controlling Mode: | normal; | Color: | Customized; |
CNC or Not: | Normal; | Power (kW): | 3; |
Voltage: | 380V; | Automatic Grade: | Automatic; |
Key Selling Points: | Easy to operate; | Port: | shanghai port; |
Dimension(L*W*H): | 2160X1070X1194MM; | Packaging Detail: | Wooden Case,Steel Pallet.; |
Weight: | 1650KG; | Warranty: | 1 YEAR; |
After-sales Service Provided: | Online support,Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Engineers available to service machinery overseas; |
SHAPPING MACHIEN
The machine is designed for cutting flat and fomed surfaces on various kinds of small or medium sized workpiece. It can also be used to cut surfaces in special shape if equipped with a special vice or a dividing head and it is suitable for single piece and small batch production as well.
The main cutting motion of the machine is linear motion being converted from circular motion of gears by link bolck mechanism. With smooth transmission.
Short over run and less consume of power, the machine is easy to start and stop.
If being provided with a tool lifter, the mechine table can obtain rapid motion in vertical and horizontal direction. The machine, with pleasing appearance and stable accuracy, can be oerated and maintained conveniently
https://smac.en.alibaba.com/product/60220680365-50021670/Shanghai_Big_Lathe_Machine_Brake_Lathe_Metal_Lathe_Heavy_Duty_Lather_for_Sale_LC6293C.html?spm=a2700.icbuShop.41413.18.3c4a78a1OBPeie
Specification\Model | Unit | 15501 | 15502 | 15503 | 15504 | 15505 | 15506 | 15507 | |
SM350 | SM500 | SM630 | SM700 | SM800 | SM1000 | SM1200 | |||
Max.Shaping length | mm | 350 | 500 | 630 | 700 | 800 | 1000 | 1000 | |
Max. distance from lower edge of ram to table | mm | 330 | 370 | 385 | 420 | 400 | 400 | 400 | |
Max.travel of table | Horizontal | mm | 400 | 500 | 630 | 630 | 750 | 800 | 800 |
Vertical | mm | 270 | 300 | 360 | 320 | 320 | 320 | 320 | |
Max.swivel angle of table | Without vice | 90 | 90 | 90 | 90 | 90 | 90 | 90 | |
With vice | 55 | 55 | 55 | 55 | 60 | 60 | 60 | ||
Max.vertical travel of tool head | mm | 110 | 110 | 120 | 125 | 160 | 160 | 160 | |
Frequecy of stroke per | min | 32, 50, 800, 125 | 15,24,37,51,64, 80,102,126,158 | 14,20,28,40, 56,80 | 11,20,38, 52,72,100 | 8,11,17,23,32, 45,64,92 | 8, 11, 17, 23, 32, 45, 64, 92 | 8, 11, 17, 23, 32, 45, 64, 92 | |
Overall Dimensions (L x W x H) | cm | 139x860 x145 | 194x117 x153 | 222x122 x148 | 255x140 x176 | 139x860 x145 | 361x157 x176 | 403x121 x193 | |
Net weight | kg | 1000 | 1800 | 1750 | 2900 | 4000 | 4200 | 5600 | |
Old model | B635A | B6050 | B6063B | BH6070 | B6080 | BY60100C | BY60120 |
