Condition: | New; | Packaging Detail: | RO-RO and Container; |
Place of Origin: | Shanghai China; | Product name: | ORIEMAC Sale 1ton 2ton 3ton 4t Self Erecting Mini Tower Crane; |
After-sales Service Provided: | Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Free spare parts,Online support; | Supply Ability: | 88 Set/Sets per Month; |
Overall height: | 3.04m; | Overall width: | 2.21m; |
Rated Loading Capacity: | 1t; | Certification: | CCC CE ISO; |
Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; | Port: | shanghai; |
Overall length: | 10.25m; | Feature: | Tower Crane; |
After Warranty Service: | Video technical support,Online support,Spare parts,Field maintenance and repair service; | Local Service Location: | Philippines,Indonesia,Chile; |
Application: | construction; | Warranty: | 1 YEAR; |
Applicable Industries: | Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Construction works ; | Showroom Location: | Philippines,Indonesia,Algeria; |
Brand Name: | ORIEMAC; | Power Supply: | 380V/50HZ; |
Color: | Yellow; |
Advantages of self erecting tower crane:
1.Without foundation, saving construction cost, low requirement for site conditions.
2.Erecting and starting rapidly.
3.None working on the high level during erecting and dismounting.
4.Mast locked automatically, jib sections connected automatically in the air.
5.No require professional operator,operating simply, mastering easily.
6.Wireless remote operating,reducing working labor strength,having wide operating view.
Transporting wholly.
Category | Item | Unit | JFYT1720-10 | JFYT2527-20 | JFYT2527-30 | JFYT2528-40 |
Hoisting parameters | Max.hoisting height | m | 17 | 25 | 25 | 25 |
Max.working radius | m | 20 | 27 | 27 | 28 | |
Max.hoisting weight | Kg | 1000 | 2000 | 3000 | 4000 | |
Hoisting speed | m/min | 16/32 | 13/26 | 13/26 | 13/26 | |
Trolleying speed | m/min | 19 | 20/40 | 20/40 | 20/40 | |
Slewing speed | r/min | 0.8 | 0.25/0.8 | 0.25/0.8 | 0.25/0.8 | |
Erecting time | min | 6 | 10 | 10 | 10 | |
Outrigger span | m | 3.5x3.5 | 4.2x4.2 | 4.2x4.2 | 4.2x4.2 | |
Dead weight | Kg | 14500 | 26000 | 32000 | 32000 | |
Travel parameters | Max.towing speed | Km/h | 15 | 15 | 15 | 15 |
Hydraulic system | Hydraulic system | Mpa | 28 | 28 | 28 | 28 |
Power supply | Rated Power | Kw | 11.4 | 23.1 | 23.1 | 23.1 |
Power supply | 380/50HZ |
