Port: | China main ports; | Packaging Detail: | By Ro-Ro.; |
Condition: | New; | Engine Capacity: | 6 - 8L; |
Approach/Departure Angle(o): | 11/13; | Vehicle structure: | Half loaded; |
Payment Terms: | L/C,T/T,Western Union,MoneyGram; | Seats: | > 50; |
Brand Name: | Shaolin; | Front/Rear Overhang (mm): | 1950/1800; |
Fuel Tank Capacity (L): | 300; | Fuel Type: | Diesel; |
Luggage compartment(m3): | 5.1; | Supply Ability: | 1000 Unit/Units per Month brand new buses; |
Wheel base (mm): | 4300; | Emission Standard: | Euro 2; |
Transmission Type: | manual; | Place of Origin: | Shandong China; |
TECHNICAL SPECIFICATION | |
Overall Dimensions |
|
Length (mm) | 10000 |
Width (mm) | 2470 |
Height (mm) | 3500( to A/C) |
Interior height (mm) | 2130 |
Wheel base (mm) | 4300 |
Front/Rear Overhang (mm) | 1950/1800 |
Min. Ground clearance(mm) | 200 |
Approach/Departure Angle(o) | 11/13 |
Vehicle structure | Half loaded |
Brake distance (v=30km/h) | ≤10 |
Kerb weight (kg) | 8800 |
Front /Rear Axle (kg) | 4000/8000 |
Max. Total Mass(kg) | 12200 |
Max. Speed (km/h) | 125 |
Max. Grade ability (%) | 30 |
Min. turning diameter (m) | 18 |
Fuel Tank Capacity (L) | 300 |
Luggage compartment(m3) | 5.1 |
Engine |
|
Arrangement of Engine | water cooling, charged air coolant, turbo charged |
Model | EQB210-20 |
Displacement (cc) | 5900 |
Position | Rear mounted |
Max. Output (kw/rpm) | 155/2300 |
Max. Torque (N.m/rpm) | 700/1500~1600 |
Type of Fuel | Diesel |
Emission Standard | Euro II |
Chassis |
|
Anti-corrosion system | Full chassis with Electrophoresis Coating |
Clutch | Strong quality and advanced durable clutch |
Gearbox | 5 Speed Manual |
Suspension system | Leaf spring suspension |
Braking system | Dual-circuit air braking Air release parking |
Tire | 9.00-16 |
Electric system | 24v Single wire, Minus earth |
Starter | 24V, electromagnetic operation |
Battery/Alternator | 2 150A alternators |
Body |
|
Body structure | Semi-integral body Pre-stress stretched panel skin Full metal body |
Anti-corrosion system | Full body with Electrophoresis Coating |
Roof hatch | ONE |
Seat | 50seats all seats with seat belt |
HEATING system | Powerful HEATER |
Audio and Visual system | MP3 USB RADIO |
Lamp
| Integral head lamp LED tail lamp LED LED interior lamp High brake lamp |
Others | Remote control locker Tool box Emergency hammers Fire extinguishers Fire extinguisher bomb Dark Grey side window |
Usually Our Truck can be shipped by Ro-ro ship or Bulk ship or Container or Flat rack.
Packing Detail: Ro-Ro or Bulk base on the ship and port in your country. If the truck on the deck,we will spray antirust paint with free. Usually we will put the truck in cabin of the ship.
Delivery Details: 15-35 days after receiving 30% deposit
Shiping Pictures:
About Chinatruck.cc
1,We Will Check Again Before Sending.
2,Spare Parts Supply:
We have our own spear parts departments,have strong production and distribution capability. We can satisfy your demand within 2-7 days. We always do our best to solve the problems, and put our customers' interests in the first place. And We can Supply Spare Parts For Many Brands, Such as SINOTRUK, BEIBEN, FAW, FOTON, IVECO, SHACMAN, SHANTUI, CIMC, DONGFENG and so on.
To see more, kindly click our spare parts website:
FAQ
Q:I want to transport the truck by container, is it ok?
A: Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
Q:How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q:I want to be your agent in my country , is that ok?
A: It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.
Q:I want the front two tyres are bias tyre and the rear 9 tyres are radial tyres, is it ok?
A: We can make the tyres as your requirement to suit your country's need.
