JL-TZ0.8-7-47 coaxial stripper /wire stripping machine/semi-auto coaxial Cable Stripping Machine Coaxial Wire Stripping Machine

Product details
Max. stripping layers:9 layers;Product name:coaxial wire stripping machine;
Stripping length:0.1-47mm;Power supply:AC220V/110V 50/60HZ;
Name:coaxial Cable Stripping Machine Wire Peeling machine;Single gross weight:60.0 KG;
Packaging Detail:wooden box;Application wire:Coaxial cable wire,auto cable;
Model Number:JL-TZ0.8-7-47;Keywords:coaxial stripper;
Selling Units:Single item;Weight:45KG;
Place of Origin:Guangdong China;Brand Name:JULI;
Single package size:92X30X45 cm;Dimensions:920x220x400mm;
Process wire diameter:0.8-7mm;Package Preview:;
Usage:Stripping;

New energy coaxial stripper /wire stripping machine/semi-auto coaxial Cable Stripping Machine Wire Peeling machine

Product Description





JL-TZ0.8-7-47 coaxial cable stripping machine

Model

JL-TZ0.8-7-47

Display

English 95mm*50mm touch screen

Power supply

AC220V/110V 50/60HZ

Power

400W

Process wire diameter

0.8-7mm

Cutting depth set unit

0.01mm

Max. stripping layers

9 layers

Dimensions

587x184x279mm

Weight

22KG

Drive mode

Servo Motor/TBI ball screw drive

Stripping mode

Rotary blade

Blade material

Tungsten steel

Working environment

-5 - 45 celsius dry and vibration free table

Production

800-1100pcs/h

Storage

99processing data

Stripping length

0.1-47mm

Application wire

Coaxial cable wire
