Variable Speed Wood Lathe

Wood Lathe Features and Functions:

1. Woodworking lathe, which consists of a bed, a tailstock mounted at the tail of the rail of the bed, a knife holder installed in the middle of the rail of the bed, a headboard mounted on the head of the bed, and mounted on the headboard The main shaft and the chuck thereon, the motor mounted on the head box, the variable speed transmission mounted on the motor shaft and the main shaft and the head box.
2. A woodworking lathe characterized in that the shifting transmission is composed of a fixed half wheel of a driven shifting cam wheel fixed to the end of the main shaft, a driven shifting cam wheel fitted on the main shaft and engaged with the fixed half wheel. a movable half wheel, a push-pull arm with a bearing mounted on the end of the movable half wheel, a compression spring mounted between the push-pull arm and the headstock, fixed on the push-pull arm parallel to the main shaft and in the hole of the head box a sliding rack, a gear shaft that meshes with the rack end through the headstock, an eccentric with a small shaft mounted in an open slot at the end of the gear shaft, mounted on the motor shaft or its connecting shaft a movable half wheel and a fixed half wheel of the active shifting cam, a compression spring mounted between the movable half wheel and the motor shaft or a ring of the connecting shaft end thereof, and a V-belt mounted on the active and driven shifting wheels It consists of a V-belt on it.
3. Woodworking machine tools for processing wood rotating surfaces or complex contours with woodworking tools. Woodworking lathes are divided into ordinary woodworking lathes, copying woodworking lathes and round bar machines.
4. Ordinary woodworking lathe The workpiece is clamped in the chuck or supported between the spindle and the tailstock for rotation. The turning tool is mounted on the tool holder, and the slide box is moved in the longitudinal or lateral direction, or the hand-held knife is fed on the bracket. Ordinary woodworking lathes are used for machining outside the car, end faces, slots and boring.
5. Woodworking lathe is a joint structure of the headstock and the feed box. It is suitable for processing workpieces with large diameter and short length. It can process steel, cast iron and light alloy parts with high speed steel or hard alloy tools. Round, inner hole, end face, taper, grooving, cutting, etc. rough and fine turning.
6. The performance of the woodworking lathe is excellent. According to the survey, it can basically be done “the people stop and stop, and do three shifts a day”. However, the premise is that timely maintenance must be carried out in accordance with the instructions. Moreover, the roughing machining can reach about 3, and the optimized design of the transmission system greatly reduces the failure rate of the machine tool. The specially processed gear system can transfer more damping torque to each axis, making the shaft The force is applied to protect the teeth.

If you are interested in our Wood Lathe, please don't hesitate to contact us.
