Stainless steel 304 mist spray nozzle,1/8 BSPT fogging nozzle with filter

Product details
Item:High pressure fog nozzle;Material:Stainless Steel;
Thread Type:1/8 BSPT;Package size per batch:20X20X15 cm;
Machinery Test Report:Provided;Video outgoing-inspection:Provided;
Marketing Type:Ordinary Product;Showroom Location:Canada;
Applicable Industries:Hotels,Farms;Applications:Cooling,Humidifying;
Condition:New;Feature:High life,low cost;
Orifice Size:0.15mm to 0.5mm;Gross weight per batch:1.0 KG;
After Warranty Service:Online support;Local Service Location:Canada;
Brand Name:Mebon;Selling Units:Multiple of 50;
Place of Origin:Guangdong China;Working pressure:20bar - 120bar;

Stainless steel 304 mist spray nozzle,1/8 BSPT fogging nozzle with filter

Product Description

  • Metal fog spray nozzle consists of stainless steel body with internal ceramic core and stainless steel guide vane (with a leak-proof device).
  • The liquid flows at high velocity under the water pressure of 20kg to 70kg, forming centrifugal swirl and spraying very fine droplet.
  • It is equipped with filter and the fog droplet sizes are about 20um.
  • Widely used in workshop moistening salt spray test,man-made fog and other moistening locations.
  • The nozzle saves 10 times or above cost than that of moistening by air.
  • Thread size: 1/8 BSPT
  • Spray pattern:full cone
  • Orifice: stainless steel,ceramics.
Performance Data
Fog Nozzle Orifice Diameter Operation Pressure Flow Rate
FD1 0.15mm 20-70kg/cm 20-46ml/min
FD2 0.20mm 49-89ml/min
FD3 0.30mm 80-145ml/min
FD4 0.40mm 95-178ml/min
FD5 0.50mm



130-243ml/min



Commen Application:

1. Wetting & Rust removal

2.Humidify for space

3.Chemical treatment

4.Chemical agent spraying

5.Liquid coating

6.Humidify for tabacco leaf

7.Pill coating

8.Evaporative cooling for flue gas

9.Disinfection & sterilization

10.Parts cooling

11.Fruit wax injection

12.Ceramic tile glazing

13.Humidify for factory

14.Salt fog test

15.Artificial fog

16.Humidify for other place
