High Quality 4G sim card LTE CPE Wireless Router 4 Antenna 150Mbps WIFI Speed support Multi Language Firmware

Product details
Routing and WiFi chipset supplier:MTK;Application:Home;
WAN Ports:1;Wi-Fi Supported Frequency:5G;
LAN Ports:2;Standards And Protocols:Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11a;
Key words:LTE Wireless Router;Wi-Fi Transmission Standard:802.11n;
Function:Voip,FireWall,QoS,VPN;Supports WDS:Yes;
Brand Name:Topleo;With Modem Function:No;
5G Wi-Fi Transmission Rate:1000Mbps;Port:ShenZhen or HongKong;
Product name:4G wireless wifi router;Certification:FCC,ce,RoHS;
Max. LAN Data Rate:150Mbps;Encryption Type:WPA2,WPA;
2.4G Wi-Fi Transmission Rate:150 Mbps;Products Status:New;
Wireless:5G;Supply Ability:500000 Piece/Pieces per Month WiFi router;
Routing and WiFi chipset model:MT7628N;Routing and WiFi processor info:IEEE 802.11 a/b/g/n;
Type:Wireless;Place of Origin:Guangdong China;
WiFi security:WPA/WPA2;Wired Transfer Rate:10/100/1000Mbps;
Packaging Detail:Carton packaging 20PCS / carton;Interface:2*lan 1*wan;
Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal;DC adapter:12V 1A;
Supports WPS:Yes;Language:Chinese&English;

            please send us an inquiry to get the latest price list and more discount

Company Information

About US---Quality---Customer Service---Honesty

TOPLEO TECHNOLOGY LIMITED is a professional high-tech enterprise with independent R&D, production lines, marketing, after services department. We are leading OEM & ODM Manufacture for tv box, mini pc, projector, air mouse and mini keyboard.

High Quality 4G sim card LTE CPE Wireless Router 4 Antenna 150Mbps WIFI Speed support Multi Language Firmware

                                                                                          LT210F Routers

Product Overviews



Product Description



Model LT210F Routers
Specification parameter
Interface Network 2*Lan, 1*Wan
SIM 2FF SIM
Buttom Reset
DC Adapter Input voltage: 12V 1A
Solution

Routing and WiFi chipset supplier

MTK
BASE  Routing and WiFi chipset model

MT7628N



Routing and WiFi processor info

IEEE 802.11 a/b/g/n



DDR/SPI

64MBytes/16MBytes



RF Main antenna
Internal antenna
Receive diversity antenna Internal antenna

WiFi band

2400MHz-2483.5MHz
MIMO for WiFi 5G 5dbi X 2
Max. transmitter power for WiFi

802.11b   22dBm±2dBm;

802.11g   18dBm±2dBm;

802.11n   16dBm±2dBm;

Software

Language

Chinese&English

APN Setting Supported

Device Settings

Supported

WIFI Settings

Supported

Routing Settings

Supported

Firewall Settings

Supported
Technical standard

LED

Supported

WiFi standard

802.11b/g/n(2*2 11n features)
WiFi security WPA/WPA2
 OS Windows XP,Windows Vista,Windows 7,Windows 10,MAC,Linux
 Browser IE (8.0 and later),Firefox (3.0 and later),Safari (4.0 and later),Opera (10.0 and later),Chrome (10.0 and later)
Envionment Operating temperature 0 to 50° C
Storage temperature -40 to 70° C
Humidity 5% to 95%
Module information
Solution Qualcomm solution CAT4

ASR CAT4

Inteface LCC LCC
Size 29.0x32.0x2.4mm 29.0x32.0x2.4mm
Wireless chipset supplier Qualcomm ASR
Wireless chipset model MDM9607 1802S
Wireless processor info CAT4 CAT4
USIM/SIM slot Standard 6 PIN SIM card interface 3V SIM card and 1.8V SIM card Standard 6 PIN SIM card interface 3V SIM card and 1.8V SIM card
Operating temperature

-20 to 60° C

-35 to 75° C

Our Services

 OEM/ODM:

1. Logo printing on housing (silk screening, gold blocking or laser carving)

2. Customized package box

3. Software Customization: Boot image, Boot animation, Launcher, UI, APP, Function… and so on

ODM:

1. PCBA design

2. Housing design: ID(Industrial Design),MD(Mechanic Design),Produce molding

3. Software Customization
