Operating Voltage: | 7.4 V; | Storage Channel: | 128; |
Single gross weight: | 0.8 KG; | Frequency Range: | 136-174MHz & 400- 520MHz; |
Feature: | Long Battery Life; | Brand Name: | BAOFENG; |
Output Power: | 5W/1W; | Talk Range: | 3-8km; |
Single package size: | 18X11X10 cm; | Step Frequency: | 2.5/5/6.25/10/12.5/20/25KHz; |
Name: | walkie talkie; | Keyword: | Cheapest Baofeng Walkie Talkie; |
Model Number: | UV-5R; | Type: | Handheld; |
Place of Origin: | Guangdong China; | Package Preview: | ; |
Temperature range: | -10℃~+60℃; | Packaging Detail: | export box; |
Selling Units: | Single item; | Certification: | CE passed,FCC,ce; |
Dimensions: | 110x58x32 mm; | Feature 2: | VOX Function; |
Feature 1: | 50 CTCSS and 104 DCS Codes; |
baofeng two way radio
1) Output : 5W/1W
2) Frequency Range: 136.00-174.00 MHz & 400.00-520.00MHz
3) Frequency Step Setting
4) High &Low Power Switchover
5) Battery Saving
6) VOX Function
7) Wide/Narrow Band Selection
8) Auto-Back Light
9) Dual Band Standby
10) Time-out Timer (TOT)
11) 50 CTCSS and 104 DCS Codes
12) Voice Prompt
13) ANI Code
14) PC or Manual Program
15) DTMF Code
16) PTT-ID
17) ATUO Keypad Lock
18) Busy Channel Lock Function
19) Dual Band, Dual Display and Dual Standby
20) Emergency Alarm
21) Priory Scanning Function
22) Relay Forwarding Confirmed (1750 HZ)
23) Low Battery Warning
24) U/V Cross Band Dual Watch
25) Dimension: 110x58x32mm
26) Packing Details: 40 Units/CTN, Carton Size: 47.5x42x50 cm
Specifications:
Frequency Range: |
136.00-174.00 MHz |
400.00- 520.00MHz |
|
Storage Channel |
128 |
Step Frequency |
2.5/5/6.25/10/12.5/20/25KHz |
Rated voltage |
DC 7.4V |
Frequency Stability |
±2.5ppm |
Work Temperature |
-20 ℃ to +60℃ |
Battery Capacity |
H-1800m Ah (Li-ion Battery) |
Battery Life |
About 12 Hours |
Frequency Combination |
PLL frequency synthesis |
Antenna Impedance |
50 Ω |
Wok Mode |
Same Frequency simplex Operation or Different Frequency simplex Operation |
Dimension |
110x58x32 mm (Excluded Antenna) |
Transmitter
Output Power |
5W/1W |
Modulation Mode(W/N Band) |
FM (F3E) |
Maximum Frequency Deviation (W/N Band) |
≤5 KHz |
Spurious Power |
≤7.5 µW |
Adjacent channel power |
≤-65dB/≤-60dB |
Audio Distortion |
<5 % |
SNR |
≥-45dB/≥-40dB |
CTSCC/DCS Frequency Deviation(W/N Band) |
0.7±0.1KHz (W), 0.4±0.1KHz (N) |
Modulation Sensitivity |
8-12mV |
Transmitting Current |
≤1500mA |
Receiver
Sensitivity |
<0.20 µ V (12dB SINAD) |
Audio Power |
1 W |
Inter modulation Interference Resistance |
≥65dB (W), ≥55dB (N) |
Adjacent channel Sensitivity (W/N Band) |
≥65dB (W), ≥55dB (N) |
Audio Distortion |
5 % |
Receiving Current |
≤ 380m A |
1 x Baofeng UV-5R walkie talkie
1 x Li-ion Battery
1 x Antenna
1 x Belt Clip
1 x ENG Manual
1 x Headset
1 x Desktop Charger
1 x big fee charge
Shipping terms
1-5 business days for sample order
5-10 business days for medium order
10-15 business days for OEM order
Delivery can be Express:DHL,UPS, FedEx, EMS, TNT; shipping logistic etc & post office for samples
Service
1. OEM & ODM serivice offered
2. Sample's fee can be refund after order reached 1000 sets.
3.Delivery can be Express:DHL,UPS, FedEx, EMS, TNT; shipping logistic etc & post office for samples
Warranty
Before delivery , we will check the items' quality strictly one by one . * 12 months for radio body & 6month for accessories warranty, please contact us immediately when you get defective,thanks
Payment terms
Payment(shown on home page to customer anti cheater ): T/T, Western Union, escrow below US$1000 accept Paypal payment term (please do NOT believe anybody by Email say Our bank changed, thank you)
About us Shenzhen ZASTONE Technology Co., Ltd. is located in Huaqiang North of Shenzhen City, which was founded in March 2004, With Supply competitive price Best quality two way radio products we established good business relationship with customers all over the world. We are glad cooperate with you, please contact Us freely to get more Information,Thank you.
1. Q: What is MOQ(mini Order Quantity)?
A: In general, it is 100pcs. According situation, it is negotiable.
2. Q: do you accept Customized?
A: yes,we did produce as customer requirement for Chile Russian Business Partner,OEM & ODM are welcomed.
3. Q: Could you offer free sample to test?
A: Yes, sure. For regular VIP agency we offer free sample when New Products Launch,for New customer you pay the sample fee first when your Order reach required amount we minus the sample Cost for you.
