Machinery Test Report: | Provided; | After Warranty Service: | Video technical support,Online support,Spare parts; |
Payment Terms: | L/C,T/T; | Type: | Fully Automatic P.p Film Laminating Machine; |
Marketing Type: | Ordinary Product; | Showroom Location: | None; |
Applicable Industries: | Manufacturing Plant; | Video outgoing-inspection: | Provided; |
New Application: | Machinery & Hardware; | Condition: | New; |
Power: | 3KW; | Key Selling Points: | Long Service Life; |
Dimension(L*W*H): | 1400mm*1200mm*1300mm; | Voltage: | 220V; |
Size: | 1400mmX1200mmX1300mm; | Rewinding Diameter: | 600mm; |
Warranty: | 12 months; | Guarrantee: | 12months; |
Port: | Shanghai; | Packaging Detail: | Wooden case; |
Certification: | CE; | Weight: | 800kgs; |
Machine Weight: | 800kgs; | Place of Origin: | Kunshan,China,Jiangsu China; |
Local Service Location: | None; | Brand Name: | DP; |
Export experience: | 10 years; | Warranty of core components: | 1 Year; |
Supply Ability: | 8 Forty-Foot Container per Year 12 months guarrantee; | Core Components: | PLC,Motor; |
dp650 industrial laminating machine
Descriptions :
The machine adopts pneumatic lifting and pressure application mechanism , more convenient for the adjustment of pressure . A rolling device ease of use heating device of fast warming cold water cooling device adopted frequency conversion speed regulation , automatic metering , stable sticking , fast , high precision , low wastage , and ease of operation .
Application :
solventless lamination machine is used for the sticking of the materials without base glue and other materials .
Main technical data :
Model : DP-650
Max Feeding Power : 2.2KW
laminating speed : 40 T/M
size : 1400mmX1200mmX1300mm
Machine Weight : 800 kgs
Rewinding Diameter : 600mm
Pictures | model | max web width (mm) | Description |
DP-420 | 420mm | roll to roll laminating machine, is applicable to sitck the narrow scope paper , IT can automatically count , set length , stop and alarm ,Complex for adhesive tape such electric label industry as mobile phone,computer and etc . | |
speed (m/min) | main motor power (kw) | accuracy (mm) | total power (kw) |
60 | 0.75 | ±0.3 | 1.5 |
