Cast aluminium low differential pressure gauge for indicating air or non-corrosive gas pressure

Supplier: Yueqing Tianen Meter Factory
Region: Zhejiang, China
Contact: Mr Joyce
Price: $15.00 / >=12 pieces
Min. Order: 12 pieces

Click here to contact

Product details

Housing Color:	Gray, golden;	Product keywords:	differential pressure gauge;
Accuracy:	±2% of FS (±3% on - 0, and ±4% on - 00,);	Port:	NINGBO, SHANGHAI;
Place of Origin:	Zhejiang China (Mainland);	Packaging Detail:	TE2000 DIFFERENTIAL PRESSURE GAUGE EXPORT STANDARD CARTONS;
Supply Ability:	50000 Piece/Pieces per Month;	Brand Name:	MAGRFHELIC;
Hot-sale Ranges:	0-60Pa, 0-500Pa, ±60Pa. 0-300MM;	Payment Terms:	T/T;
Model Number:	TE2000;	Pressure Rating:	15 PSI (1.03 bar);
Brand Name:	MAGRFHELIC;	Weight:	0.55kg;
Ambient Temperature:	-7 ~ 60 °C;	Product Name:	Differential Pressure Gauge;
Delivery Detail:	3-15 days according to quantity after payment;	Range:	30Pa~80KPa (Special ranges also can be customized );

Cast aluminium low differential pressure gauge for indicating air or non-corrosive gas pressure

Product Description

INTRODUCTION About TE2000 Differential pressure gauges

Series TE2000 MAGRFHELIC® Differential Pressure Gauges are widely utilized for measuring pressure of fan and blowing machine, resistance of filter, wind speed, furnace pressure, differential pressure of pore plate, the pressure of drum water level, liquid amplifier and hydraulic pressure system. Meantime, they are used to control the automatic valve and specific value of air-producer gas in combustion and they are used to test blood pressure and respiratory pressure in medical health care equipment. There are more than 81 models to suit your needs precisely. The key components adopt import materials.

SPECIFICATION

TE2000 DIFFERENTIAL PRESSURE GAUGE
Pressure Rating	15 PSI (1.03 bar)
Ambient Temperature	20° to 140° F (-7 to 60 ℃)
Overpressure	Protective rubber stopper will be blown out if rated pressure is up to about 172KPa.
Process Connections	Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 hour salt spray corrosion test
Accuracy	±2% of FS (±3% on -0, and ±4% on -00,)
Range	30Pa~80KPa (Special Specification also can be ordered.)
Weight	0.55 kg
Dimensions	4-3/4 "dia. x 2-3/16"deep
Housing Color	Gray, golden
Connections	1/8"female NTP high and low pressure taps, duplicated, one pair side and one pair back.

PRODUCT SHOW Two colors options— Grey, Golden

ACCESSORIES Of TE2000 Differential pressure gauges

RANGES various ranges can be ordered

RANGES FOR REFERENCE	Pa	Kpa	Inches of Water	MM of Water	Dual Scale
	0-30	0-0.5	0-.25	0-6	in w.cc	Pa or Kpa
	0-60	0-1	0-.50	0-10	0-.25	0-62 Pa
	0-100	0-1.5	0-1.0	0-15	0-0.5	0-125 Pa
	0-125	0-2	0-2.0	0-25	0-1.0	0-250 Pa
	0-300	0-5	0-8.0	0-30	0-2.0	0-500 Pa
	0-500	0-8	0-10	0-50	0-3.0	0-750Pa
	-30-0-30	0-10	0-20	0-80	0-4.0	0-1.0kPa
	-60-0-60	0-20	0-50	0-100	0-5.0	0-1.25kPa
	-100-0-100	0-30	0-100	0-125	0-6.0	0-1.5kPa
	-250-0-250	0-50	0-180	0-200	0-8.0	0-2.0kPa
	-500-0-500	0-60	0-250	0-300	0-0.5	0-2.5kPa
	Bold Ranges Are Hot Sale
	VARIOUS RANGES CAN BE CUSTOMIZED FOR YOU

DIMENSIONAL DRAWING

MOUNTING DRAWING

PRODUCTION PROCESS we are professional and concentrative

Packaging & Shipping

PACKAGE Packing is well suited for long distance shipments

CARTON SIZE: 46.5*34.5*36.5 (CM)

NET WEIGHT: 446.5 G/PCS GROSS WEIGHT: 446.5 G/PCS

WEIGHT OF ACCESSORIES: 38.9 G/SET

PACKAGE: 24PCS/CTN

SHIPPMENT

You can transport goods by sea, by air, by express or another shiping ways.

We will do our best to help you find an optimal way.

Company Information

ABOUT US We focus on differential pressure gauge for 18 years

Yueqing Tianen Meter Factory, established in 2000 and located in Zhejiang Province, Wenzhou City. Tianen is a leading manufacturer of differential pressure gauge, differential Pressure Manometer, differential pressure switch, float control switch, water level controller, capsule pressure gauge, etc. With 18 years of experience in this industry market. Tianen has professional team of R&D and production, management, technical equipment and hardworking and experienced employees. We sincerely believe “Quality is business life ” which makes us developed rapidly in past few years. We’re professional enough and deserve your choice!

OUR CERTIFICATES We have letter of patent, CE certificates and explosion proof certificates

Our Services

WHY CHOOSE US?

1) PROFESSIONAL: We're professional manufacturer with technical equipment and trained employees

2) STRICK QUALITY CONTROL: We have strict Quality Control System to ensure quality of goods

3) COMPETITIVE PRICE: High quality level with competitive price to help you gain competitive advantage

4) GOOD SERVICE: Provide good service in all process

5) OEM ARE WELCOMED: We accept any kinds of OEM design, and try our best to meet the request

6) VIP FAST PRODUCTION: Goods will be done at the time of delivery and be shipped safely to make customers at ease.

FAQ

Q1) Can you make the goods based on our requirement?
Yes, any kind of OEM design is warmly welcomed, and send me your deatiled request and we will try our best to meet.
Q2) How can I get the samples?
  We can provide samples according to your request. However, pls be kind in pay the sample cost and freight, and sample cost will be fully returned when mass order confirmed. For some range, we can provide you free samples (Within 2pcs), you juest need to pay the postage.
Q3) What's the delivery time ?
  For common ranges, we have a number of inventory, we could dispatch them immediately. For small order, it needs about 3 days. For large order, it needs 1-3 weeks depending on quantity.
Q4) How can I trust you?
  We're engaged in this field for about 18 years. As the sole representative in the industry, Tianen was invited by Beijing Institute of Metrology to draft the calibration regulation of differential pressure gauge in 2017. we have good experience in domestic trade and export trading. We have our own factory, always welcome your visit.
