Place of Origin: | Zhejiang China; | Payment Terms: | T/T; |
Condition: | New; | Certification: | ce; |
Brand Name: | ZUUMAV; | Voltage: | 12V; |
Fuel: | Gas / Diesel; | Power: | > 2000W; |
Package Preview: | ; | Port: | Ningbo Shanghai; |
Max. Speed: | > 80km/h; | Displacement: | 450cc; |
Supply Ability: | 2500 Piece/Pieces per Month; | Brake(F/R): | Disc/Disc; |
Engine Type: | 4-Stroke; | Dirt bike: | Dirt Bike Fast Racing Motocross; |
Packaging Detail: | ningbo size: 1710x445x860mm 145KG 1PCS; | Type: | Dirt Bike; |
SPECIFICATONS | ||
POWER | ||
Engine Type | NC450, Single Cylinder, 4-Valve, Liquid Cooled, Balance Shaft | |
Displacement | 448.6 ml | |
Max Power | 35kw/9000rpm - 48 Hp | |
Max Torque | 40N·m/7000rpm | |
Compression Ratio | 11.6:1 | |
Shift Type | Manual Wet Multi-Plate, Constant mesh, two stage transmission, 5-Gears | |
Start Type | Electric & Kick Start | |
Carburetor | PWM40 | |
Ignition | Digital CDI | |
Drive Train | #520 Chain, FT: 13T/RR: 49T Sprocket | |
PERFORMANCE | ||
Front Fork | Φ54*Φ60-940mm Inverted Hydraulic Dual Adjustable Forks, 300mm Travel | |
Rear Shock | 482mm Dual Adjustable Shock with Ballonet, 120mm Travel | |
Front Wheel | 7116 Aluminum Rim, Gravity Cast Hub, FT: 1.6 x 21 | |
Rear Wheel | 7116 Aluminum Rim, Gravity Cast Hub, RR: 2.15 x 18 | |
Front Tires | 80/100-21 | |
Rear Tires | 110/100-18 | |
Front Brake | Dual Piston Caliper, 270mm Disc | |
Rear Brake | Single Piston Caliper, 240mm Disc | |
DETAILS | ||
Frame | Zuumav Aluminum Perimeter Frame | |
Swing-Arm | Forged Aluminum Swingarm,L=590mm | |
Handle Bar | Tapered Aluminum #7075 | |
Overall Size | 2170x800x1310 mm | |
Packing Size | 1715x445x860mm | |
Wheel Base | 1490 mm | |
Seat Height | 950 mm | |
Ground Clearance | 300 mm | |
Fuel Capacity | 6.5 L / 1.72 Gal. | |
N.W | 115KG | |
G.W | 145KG |
