payment terms: | wire transfer | port: | Ningbo Shanghai |
Shift: | 110cc | fuel: | gas/diesel |
Brakes (Front/Rear): | CD | State of health: | new |
place of origin; place of origin: | China | Certification: | ce |
Engine type: | Four-stroke | maximum. speed: | > 80 km/h |
SUV: | dirt bike fast racing motocross | Package preview: | |
Packaging Details: | Ningbo Size: 1405*380*675CM 59.5 KG 1PCS | Voltage: | 12V |
Types of: | SUV | strength: | > 2000W |
Supply capacity: | 2500 pieces per month |
Specification | ||
strength | ||
engine type | 110CC, single cylinder, four-stroke, air-cooled | |
shift | 107 ml | |
Bore x stroke | Ф52.4×49.5mm | |
Maximum power | 5.0/8000±500 kW/rev/min | |
Maximum torque | 7.5/5500±500 Nm/rev/min | |
Compression ratio | 9.0:1 | |
shift type | Automatic clutch, first gear | |
start type | electric start | |
ignition | CDI | |
transmission system | #420 Chain, FT: 14T/RR: 39T Sprockets | |
Performance | ||
front fork | Φ39*Φ42-590mm inverted hydraulic fork, stroke 100mm | |
rear shock absorber | 10*270mm non-adjustable rear shock, 50mm travel | |
front wheel | Aluminum rim, ft: 1.40 x 12 | |
rear wheel | Aluminum rims, RR: 1.60x 10 | |
front tire | 2.75-12 | |
rear tire | 3.00-10 | |
front brake | Single-piston caliper, 190mm disc | |
rear brake | Single-piston caliper, 190mm disc | |
detail | ||
frame | Cradle steel pipe frame | |
rocker arm | Tubular high-strength steel swingarm | |
handlebar | Aluminum #6061 | |
total measurement | 1520*650*840mm | |
Package dimensions | 1405x380x675mm | |
wheelbase | 1000 mm | |
chair height | 620mm | |
Ground clearance | 210mm | |
fuel capacity | 2.2 liters/0.58 gallons. | |
northwest | 52.5KG | |
gross weight | 59.5KG |
