Motorhome 12v 100ah lifepo4 battery with smart bms 12V 100Ah Lithium Ion Battery Packs For RV Solar System Yacht Golf Carts

Supplier: Dongguan junda New energy Technology Co.Limited
Region: China
Contact: Mr andrew gao
Price: $325.00 / 1 - 500 pieces
Min. Order: 1 piece

Click here to contact

Product details

Motorhome 12v 100ah lifepo4 battery with smart bms 12V 100Ah Lithium Ion Battery Packs For RV Solar System Yacht Golf Carts specification:

No.	Item	General Parameter	Remark
1	Rated Capacity	100.0Ah	Standard discharge(0.2 C5)after standard charge(0.2 C5)
2	Minimal Rated Capacity	95.0Ah	Standard discharge(0.2 C5)after standard charge(0.2 C5)
3	Nominal Voltage	12.8V
4	Cycle Life	Higher than 60% of the Initial Capacity of the Cells	Charge: CC 0.2C to 14.6V, then CV till current to 0.05C Rest: 30min. Discharge: 0.2C to 10.0V Temperature:20±5℃ Carry out 2000cycles
5	Discharge cut-off voltage	10.0V	10.0V( recommended)
6	Charging cut-off voltage	14.8V	14.6V (recommended)
7	Standard charge	0.2C constant current(CC) charge to 14.6V,then constant voltage (CV)14.6V charge till charge current decline to ≤0.05C	Charge time : Approx 7h
8	Standard discharge	Constant current 0.2C Cut-off voltage 10.0V
9	Maximum Charge Current	100A
10	Continuous Discharge Current	200A	Over current 100±5A 9mS
11	Operation Temperature Range	Charge: 5~45℃	60±25%R.H.
12		Discharge: -10~60℃
13	Storage Temperature Range	Less than 1 year : 0~25℃	60±25%R.H. at the shipment state
		Less than 3 months:-5~35℃
14	Weight	Approx: 6.1Kg
15	Max.Dimension	Height:182mmWidth: 130mmLength: 195mm

Motorhome 12v 100ah lifepo4 battery with smart bms 12V 100Ah Lithium Ion Battery Packs For RV Solar System Yacht Golf Carts feature:

Environmental friendly.

High density of energy.

Light weight.
Low self-discharge.
Low internal resistance.
Long cycle life, chargeable up to 1000 times.

No memory effect.

No fire, No explosion, No leakage.
