Ct 312 Multiprocess Mos 3 in One Mma Tig Cut Welder Blue Stainless Steel 0.2-0.4mpa 410*155*300 Automatic CE/ROHS/TUV 10A-110A

Click here to contact
Product details
Protection Grade:IP21S;Place of Origin:China;
Payment Terms:L/C,Western Union,D/P,D/A,T/T,MoneyGram;Certification:CE/ROHS/TUV;
Supply Ability:3500 Sets per Month;Output Current Range(MMA):10A-110A;
Power (kW):3.5;Machinery Test Report:Not Available;
Marketing Type:Ordinary Product;Applicable Industries:Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Printing Shops,Construction works ;
Output Current Range(TIG):10A-120A;Warranty:1 Year;
Key Selling Points:Automatic;After Warranty Service:Video technical support,Online support,Spare parts;
Warranty of core components:1 Year;Brand Name:RETOP;
Arc Start:HF;gas pressure:0.2-0.4mpa;
Power Factor:0.93COS;Core Components:IGBT;
Showroom Location:India,Mexico,Russia,Sri Lanka,Ukraine;Video outgoing-inspection:Not Available;
Input Voltage:AC230V;Condition:New;
Rated Current:10-30A;Local Service Location:India,Mexico,Russia,Sri Lanka,Ukraine;
After-sales Service Provided:Overseas service center available,Free spare parts,Online support,Video technical support;Color:blue, or customer specified;
Packaging Detail:Standard export cartons with plastic foam normally;Dimensions:410*155*300;
Weight (KG):9 KG;Port:SHANGHAI/NINGBO;
Type:Other;Input power frequency:50/60Hz;
Product Description
Features
1. Advanced inverter technology, energy-efficient and low noise.
2. Use compressed air as cutting gas source, cost-effective.
3. Air pressure and cutting current adjustable.
4. Easy operation, narrow cutting seams, smooth cutting performance and less deformation.
5. Circuit protection against over current, over voltage and over heat.
6. Suitable for cutting carbon steel, stainless steel, alloy steel, copper and aluminum, etc.
7 .Widely used in iron structure construction, manufacturing and automobile maintenance.
Technical Specifications
ITEM
UNIT
CT-312
CT-416
CT-520
Input Power Voltage
V
AC380V±10%
AC380V±10%
AC380V±10%
Input Power Frequency
Hz
50/60
50/60
50/60
Rated Input Capacity
KVA
3.5
4.5
5.5
Output Current Range (MMA)
A
10-110
10-140
10-160
Output Current Range (TIG)
A
10-120
10-160
10-190
Output Current Range (CUT)
A
10-30
10-40
10-50
No-load Voltage
V
230
240
240
Rated Duty Cycle
%
60
60
60
Arc Start
HF
HF
HF
Power Factor
cosΦ
0.93
0.93
0.93
Air Pressure
mpa
0.2-0.4
0.2-0.4
0.2-0.4
Protection Grade
IP21S
IP21S
IP21S
Dimensions
MM
410*155*300
460*210*360
510*210*360
weight
Kg
8.6
12.7
17.8
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.

b. We use all new components,mosfet tube, diode, capacitor and so on imported components.

c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.

d. We provide Warranty period of 1 year for all our items
