Newest and most popular 5 ton electric city transport truck QX5TEV SKD/CKD for sale

Supplier: Hubei Qixing Truck Cabin Manufacturing Limited Company
Region: Hubei, China
Contact: Mr QI XING
Price: $750.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

port:	any port in China;	Curb weight:	2550;
Packaging Preview:	;	Supply capacity:	20,000 units per year;
capacity:	3 seats;	motor:	5kW / 7.5kW;
Battery:	lithium battery;	payment terms:	L/C,Western Union,T/T,MoneyGram;
Maximum speed:	100 km/h;	Dimensions (LWH):	599518902850mm;
place of origin; place of origin:	China;	gasoline:	electrical;
Charging time:	6-8 hours;	Wheel Bottom (mm):	3200MM;
Packaging Details:	1. CBU Condition: ROLL-ROLL 2. SKD/CKD Condition: Standard packed into 20/40' container;	product name:	high-speed electric vehicles;

Technical Specifications:

model.	QX5TEV
truck size	L×W×H:	5780×1905×2690mm
	wheelbase	3300 mm
weight	gross weight	5,000 kg
	Curb weight (without cargo box)	2,360 kg
Performance	recharge mileage	250-300 km
	Maximum speed	90-120km/h
Battery	type	Lithium iron phosphate or ternary lithium
	Rated Capacity	70-100 kWh
motor	type	Permanent Magnet Synchronous Motor
	peak power	115kW
	range of working temperature	-40~135°C
charging type	standard	slow charging
	optional	fast charging
chassis	front axle	Front axle rated load 2000 KG
	rear axle	Rear axle carrying capacity 3500kg
		Rear axle ratio 6.167
	fetal	215/75R16LT
	Braking System	One-piece hydraulic four-channel ABS assembly
		FR: Disc RR: Drums

company information

We are the largest cabin and tanker manufacturer in Central China, Seven Star Group, we provide products involving aluminum/steel tanker semi-trailer, water tanker, milk tank, chemical liquid tank, cement tank, LPG storage tank and LPG tank trailer piece. At the same time, we can provide different types of heavy and light cabins, caravans, etc.

Qixing tankers and cabin products have complete design, production and testing facilities, which have been supplied to major Chinese automobile manufacturing and transportation companies, and exported to the United States, Russia, Ukraine, Brazil, Iran, Laos and other countries. In 2015, Qixing Group had a turnover of US$1.5 billion and 4,000 employees.

Production Process:

our service

1. Design new truck cabs, SKD/CKD trucks, electric trucks and their related tooling for different purposes;
2. Design new interiors and exteriors;
3. Develop new molds and tooling & fixtures;
4. Design and production of interior parts such as door trim panels, instrument panels, ceilings, floor mats, etc.;
5. A full set of production lines for stamping, welding, painting, final assembly, and testing;
6. Retrofit existing cabins, trucks and electric trucks to meet customer requirements;
7. Design powertrain and brand new diesel trucks and electric trucks.

FAQ

Market and Customers

overseas market:

Domestic market:

Hubei Qixing Body Manufacturing Co., Ltd.
(A wholly-owned subsidiary of Seven Star Group Corporation)
Tel: 0086-722-3262617
Fax: 0086-722-3261281
Address: No. 2, Lieshan Avenue, Suizhou City, Hubei Province, China
Website: www.qixingauto.com or https://qixingauto.en.alibaba.com
