payment terms: | Letter of Credit, T/T, Western Union, MoneyGram | color: | red blue green black white etc |
minute. Line width: | 1/2 oz. Copper .003" +/- .0005" (0.0762mm) | Copper Thickness: | 1/3 oz ~ 6 oz |
Surface treatment: | HAL, HASL lead-free, immersion gold, gold plated | place of origin; place of origin: | Fujian China |
minute. Line spacing: | 1/2 oz. Copper .003" +/- .0005" (0.0762mm) | minute. Hole size: | 0.1mm (4mil) |
Substrate: | FR-4, Hi-TG FR4, CEM-1, CEM-3, TACONIC, Metal/Ceramic | Plate thickness: | 0.4-3.0mm |
brand: | custom made | model: | L23 |
layers | 1-28L, HDI |
Material | FR-4, High TG FR4, Aluminum, FPC |
Teflon, Teflon (F4B, F4BK), Rogers (4003, 4350, 5880) | |
Maximum board size | 800mm*620mm |
plate shape | Rectangular, Round, Slotted, Cut, Complex, Irregular |
plate type | rigid, soft, rigid |
Sheet cutting | Cut, V-Score, Label Routing, Submerge |
plate thickness | 0.2~8.0mm, bending 0.1~0.25mm |
Thickness tolerance | ±10% |
Minimum line width/spacing | 3 million/3 million |
Minimum Drilling (Mechanical) | 0.1mm |
Minimum laser hole | 0.075mm |
Blind Via/Buried Board | Yes |
Hole Position/Hole Tolerance | Through hole: ±0.076MM |
Net weight: ±0.05mm | |
Inner layer copper thickness | 0.5-3 oz |
Outer copper thickness | 0.5-4 oz |
Impedance Control Tolerance | ±10% |
surface treatment | Spray tin, lead-free spray tin, gold and silver, immersion tin, immersion silver, OSP... |
Solder mask | Double-sided green, red, white, blue, black, etc. |
silk screen | Double-sided or single-sided white, black or negative film |
PCB testing | Electronic test, flying probe test |
Acceptable file formats | Gerber RS-274X, 274D, AutoCAD'S DXF, DWG, Pro-E, Ki-CAD |
Quality Standard | IPC-A-600F and MIL-STD-105D China GB<4588> |
Types of PCB Assembly | SMT (Surface Mount Technology) |
THT (Through Hole Technology) | |
Hybrid (Surface Mount and Through Hole) Technology | |
cable assembly | |
Components | Passive components: as small as 01005, 0201 |
BGA, uBGA, QFN, POP, SOP, SSOP, PLCC, LGA | |
Fine pitch parts: 0.25mm fine pitch parts | |
Maximum component height: 25mm (SMT), top 120mm/bottom 15mm (wave soldering) | |
component package | Reels, Cutting Tape, Tubes and Trays, Loose Parts and Bulk |
board size | Minimum board size: no limit |
Maximum board size: 680 x 500mm | |
plate shape | We can assemble rectangular, circular and irregular boards |
plate type | Rigid PCB, Flexible PCB, Rigid-Flex PCB |
Assembly process | lead Lead-free (RoHS) |
Design file format | Gerber RS-274X BOM (Bill of Materials) (.xls, .csv, .xlsx) Centroid (Pick-N-Place/XY file) |
Electrical test | X-ray inspection AOI (Automated Optical Inspection) function test |
Certificate | ISO13485, IATF16949, ISO9001, ISO14001 |
Quality Standard | IPC-A-600/IPC-A-610 Compliance |
Service type | Turnkey, partial turnkey or consignment |
Subassembly | plastic case, metal case, screen |
silk screen | Double-sided or single-sided white, black or negative film |
PCB testing | Electronic test, flying probe test |
Acceptable file formats | Gerber RS-274X, 274D, AutoCAD'S DXF, DWG, Pro-E, Ki-CAD |
Quality Standard | IPC-A-600F and MIL-STD-105D China GB<4588> |
