Packaging Details: | carton/pallet/wooden case | product name: | solar air conditioner |
Solar panels: | 275-340w | place of origin; place of origin: | China |
payment terms: | L/C,Western Union,T/T,MoneyGram | model: | RC-ADC12GW-XA |
Voltage: | 90-380V | Capacity (Btu): | 12000btu |
application: | family | Certificate: | CE/CB/EMC/IEC/GCC/SASO |
Cooling/Heating: | cooling/heating | Cooling capacity: | 12000btu |
Energy source: | electricity, solar | brand: | Albgrin |
feature: | 100% Solar | type: | Split Wall Mounted Air Conditioner |
Warranty: | 3 years - complete system, 5 years - compressor |
model. | RC-ADC12GW-XA-R32 | RC-ADC18GW-XA-R32 | RC-ADC24GW-XA-R32 | ||||
power supply | solar energy | five | DC90-380V Max.15A | ||||
AC power connected | five | 180-240V(50/60Hz) | |||||
cool down | Rated cooling capacity | btu/hour | 12000 | 18000 | 24000 | ||
Cooling capacity range | btu/hour | 3482-13561 | 3681-18846 | 4594-24582 | |||
Rated input power | kilowatt | 1.06 | 1.42 | 1.79 | |||
Rated current (AC) | One | 4.28 | 5.96 | 8 | |||
prophet | 25 | twenty four | twenty four | ||||
Indoor Air Flow - (Hifan) | cfm | 690 | 1080 | 1210 | |||
Indoor noise decibel (A) | dB/A | 38 | 42 | 45 | |||
Maximum cooling tube length | ftm | 15 | 15 | 15 | |||
Max Refrigeration Pipe Up/Down | ftm | 5 | 5 | 5 | |||
maximum elevation difference | 15 | 15 | 15 | ||||
design pressure | psig | 600/345 | 600/345 | 600/345 | |||
connect | type | flare | flare | flare | |||
Connection wiring | Arbitrary Waveform Generator | 4*18AWG | 4*18AWG | 4*18AWG | |||
Operating temperature | Indoor (cooling/heating) | °F | 60.8-89.6/60.8-89.6 | 60.8-89.6/60.8-89.6 | 60.8-89.6/60.8-89.6 | ||
Outdoor (cooling/heating) | °F | 50-125.6/5-104 | 50-125.6/5-104 | 50-125.6/5-104 | |||
Indoor unit | Dimensions (W*D*H) | mm | 850*190*292 | 960*215*300 | 1042*220*320 | ||
Packaging(W*D*H*) | mm | 910*265*350 | 1015*265*360 | 1135*305*395 | |||
Net weight/gross weight | Kilogram | 9.2/12 | 12.5/14.5 | 15.5/17.5 | |||
The outdoor unit | Dimensions (W*D*H) | mm | 795x290x555 | 790x290x555 | 860x304x733 | ||
Packaging(W*D*H*) | mm | 910*400*630 | 910*400*630 | 910*400*630 | |||
Net weight/gross weight | Kilogram | 31/35 | 35/39 | 51/55 | |||
approve | CB/CE/GCC/SOAO/ETL performance certification | ||||||
Container Loading 20'/40'/40'HQ | 84/174/216 | 78/171/212 | 54/118/131 |
