Supply capacity: | 500,000 pieces per month | product: | Composite rivets |
model: | AgCdO12 | Name: | silver contacts |
use: | for relay contactors | Packaging Details: | carton |
place of origin; place of origin: | China Shanghai | payment terms: | L/C,D/A,T/T,Western Union |
brand: | tank | port: | Shanghai |
Features
This contact piece can be welded or riveted. When riveting, it should be noted that the length of the rivet foot is 0.5mm to 0.8mm larger than the thickness of the rivet piece to ensure the riveting strength. It should be a matching riveting equipment. For specific matters, please contact the company.
Material
Material: Ag, AgCdO12, AgCdO12/Cu, AgCdO15, AgCdO15/Cu, AgNi10, AgNi10/Cu, AgSnO2/Cu, AgZnO, AgSnO2, AgSnO2In2O3
All-Silver Model: Widely used for frequent contact.
Sophisticated: Designed to keep costs down.
Tube Type: Designed for riveting onto fragile bases such as bakelite.
Special type: The special type contact has the characteristics of tubular HCC, which is pressed in combination with the contact manufacturing method. This new product solves the designer's single-stroke problem.
Launch: Designed for automated welding on bimetallic tape beds.
Cant type: Fuller riveting for terminals designed in automatic feeding systems.
Properties and uses of two composite rivets
project |
Nail head diameter Dmm |
Nail head thickness T/mm |
Composite layer thickness Um |
Pin tail diameter Dmm |
Tail length of pin Lmm |
Sphere radius Rmm |
Injection angle θ (°) |
size |
2.5 |
0.6, 0.8, 1.0 |
0.3~0.4 |
1.2, 1.5 |
1.0~2.0 |
4,6 |
9 |
4.0 |
1.0, 1.2, 1.5 |
0.35~0.50 |
2.0 |
1.0~3.0 |
8,10 |
||
5.0 |
1.0, 1.2, 1.5, 2.0 |
0.40~0.60 |
2.5 |
1.0~3.0 |
10,15 |
||
8.0 |
1.2, 1.2, 2.0 |
0.50~0.70 |
4.0 |
1.0~3.0 |
20,25 |
||
tolerant |
±0.1 |
±0.05 |
|
|
|
±0.2R |
±2 |
Unit: mm
head diameter |
2.3~3.0 |
>3.0~6.0 |
>6.0~8.0 |
Coaxiality error |
≤0.12 |
≤0.15 |
≤0.20 |
Properties and uses of three composite rivets
project |
Nail head diameter Dmm |
Nail head thickness T/mm |
Pin tail diameter Dmm |
Tail length of pin Lmm |
Sphere radius Rmm |
Nailhead Multilayer Jacket S1mm |
Nailhead Multilayer Jacket S2mm |
Injection angle θ (°) |
size |
3.0~4.8 |
0.8~1.5 |
1.5~3.5 |
1.2~4.0 |
6~20 |
0.3~1.1 |
0.4~1.2 |
7~11 |
tolerant |
±0.1 |
±0.05 |
|
±0.2R |
|
±2 |
Unit: mm
head diameter |
3.0~4.5 |
>4.5~6.8 |
Coaxiality error |
≤0.12 |
≤0.15
|
