Automatic Vertical and Horizontal Polyurethane Mattress Foam Cutting Machine

  • Supplier: Shandong Hightop Group
  • Region: Shandong, China
  • Contact: Ms Kerry Chen
  • Price: $2000.00 /piece
  • Min. Order: 1 piece
Click here to contact
Product details
brand:China Nonferrous Metals GroupCutting Foam Height:more than 2 mm
Processing type:Foaming machineSupply capacity:Foam cutting machine 1000 pieces per month.
color:Foam cutting machine pictureCertification:ce
Outside table size:W1200mm*L2290mmPackaging Details:carton
application:foam cuttingweight:950kg
Product Category:foam cutterproduct name:Automatic Vertical Horizontal Polyurethane Mattress Foam Cutting Machine
place of origin; place of origin:Shandong Chinastrength:1.68KW
Warranty:1 yearDimensions (L*W*H):L3500mm*W4500mm*H2400mm
Inner table size:W1320mm*L2290mmmanufactures:foam block
port:Qingdao Port Automatic Vertical and Horizontal Polyurethane Mattress Foam Cutting Machine.payment terms:L/C,T/T,Western Union
Type of machine:Cutting MachineKey words:foam cutter
Blade Tension System:select availableAfter-sales service provided:Video technical support, online support
Voltage:220VHealth status:new

Automatic Vertical and Horizontal Polyurethane Mattress Foam Cutting Machine

Product Description

1. Foam cutting machine is used for foam block cutting. It can also cut PU, PE, PVC, etc. and other soft materials.

2. Using advanced linear track, the cutting is accurate. Simultaneous production of various EVA, pearl plastic profiles.

Automatic Vertical and Horizontal Polyurethane Mattress Foam Cutting Machine

1. Adopt high-speed hydraulic system to improve cutting speed.

2. This machine can be used for cutting through machine.

3. The servo motor positioning system maintains the positioning accuracy of ±0.1mm, which can save up to 20% of the material cost.

4. Automatic feeding by belt. Material is fed from one side of the machine and output from the other side of the machine after die cutting. Workers only need to pick up the cut finished product, which greatly improves production efficiency.

5. Extremely strong structure maintains parallelism and ensures high precision stamping accuracy.

6. Cutting table size and cutting force can be customized according to customer requirements.

type:

ECMT-109

ECMT-110

Inner table size:

W1320mm*L2290mm

W1720mm*L2290mm

Outside table size:

W1200mm*L2290mm

W2000mm*L2290mm

Cutting Foam Height:

more than 2 mm

more than 2 mm

Cut size:

L2000mm×W1200mm

(2000mm)×H1200mm

L2000mm×W1200mm

(2000mm)×H1200mm

Blade length:

L7690mm*W30mm*T0.45mm

L8500mm*W30mm*T0.45mm

Blade Tension System:

select available

select available

Machine Northwest:

950kg

1100kg

Total motor power:

1.68kW

1.68kW

construction area:

L3500mm*W4500mm

*H2400mm

L4500mm*W5200mm

*H2400mm

application

our service

1. 24 hours online service, Support Chinese, English, Spanish, French, German, Russian, technical guidance.



2. In case of machine failure, our factory guarantees to solve it within 1 hour.



3. Provide machine installation video.



4. Provide logistics information, such as shipping, DHL express, FEDEX delivery, real-time tracking service.



5.If the machine is broken, for non-human reasons, a new machine will be provided or new parts will be provided.
