Free training wds 720 cell phone bga rework station with optical alignment hd camera

Product details
usage:mobile ic ball transfer stationTotal power:4200W
Supply capacity:999 pieces per month is wds 720 cell phone bga rework stationApplicable industries:Mechanical Repair Shop
current:credibleaspect:L450*W480*H670mm
After Warranty Service:Video technical support, online support, spare parts, on-site maintenance and repair servicesAfter-sales service provided:Engineers can service machinery overseas, free spare parts, on-site installation, commissioning and training, video technical support, online support
Health status:newWeight (kg):70
Main selling point:Precise temperature controlBGA chip size:Maximum: 60*60mm, minimum 1*1mm
port:Shenzhen Hong KongMarketing Type:normal product
train:Free trainingplace of origin; place of origin:Guangdong, China
Warranty:1 year, lifetime maintenance, 1 yearMechanical test report:if
Core Components Warranty:1 yearVoltage:110V/220V
Rated Duty Cycle:100%brand:WDS
payment terms:Western Union, T/T, MoneyGram, PayPalCertification:EU standard
Board size:Maximum: 140*160mm, minimum 5*5mmShowroom location:not any
Local service location:not anyRated Capacity:4200W
Upper heating power:1200WLower heating power:1200W , IR 1800W
Electrical Materials:High sensitivity temperature control module, touch screen (Taiwan)Packaging Details:Standard wooden box packing or free training wds 720 mobile phone bga rework station with optical alignment hd camera according to customer requirements
Type of machine:bga rework stationVideo external inspection:if
Targeting:V-shaped card slot, PCB bracket X, Y axis adjustableCore components:programmable logic controller

Welcome to the wds 720 product window and have fun.

 Free training wds 720 cell phone bga rework station with optical alignment hd camera



Product Description

Main features of WDS-720 ic reballing kit:

             Simple operation, 100% success rate, automatic entry and exit

1). Automatic soldering, desoldering and installation. 5 models

2). High-resolution optical alignment system and high-definition camera system + 3-axis fine-tuning, precise bga position. Ensure precise installation.

3).Many nozzles of different sizes, also can be customized.

4).3 Temperature zone control. The top and bottom are heated by hot air, and the third is heated by laser. Can work independently.

5). Features strong cross flow and 1 external temperature sensor socket.

6). High sensitivity touch screen, controlled by Panasonic PLC.

7). Alarm function and double over temperature protection.

8). CE.ISO9001 certified.

9). Optical alignment camera automatic in and out switch



Parameters of WDS-720 bga rework station:



thing quantity
total power 4200W
Upper heating power 1200W
lower heating power 1200W , IR 1800W
model WDS-720 bga chip conveyor
Dimensions L450*W480*H670mm
Applicable circuit boards Maximum 260*260mm Minimum 5*5mm
Applicable integrated circuits Maximum 60*60 Minimum 1*1mm
power supply AC220V/110V , 50/ 60Hz
weight 40kg
Electrical materials Drive motor + PLC intelligent thermostat
Controller + color touch screen
positioning mode V-shaped card slot,
PCB bracket can adjust X&Y axis with universal clamp



Detailed display of WDS-720 bga rework station:



Features of WDS-720 bga chip conveyor:

Independent 3 heating zone temperature control system
1. The upper and lower hot air heating can be simultaneously heated from the top of the component to the bottom of the PCB, and the temperature accuracy is controlled within ±1°C.

8 temperature independent control.
2. Adopt high-precision K-type thermocouple closed-loop control and PID parameter self-tuning system; can display 4 temperature curves, with real-time curve analysis function

Multiple sets of user data can be saved; temperature can be accurately measured through an external measurement interface, and curves can be analyzed, set and calibrated on the touch screen at any time.

Precision Optical Alignment System
Adopt high-definition adjustable CCD color optical alignment system, splitting, zooming in, zooming out, fine-tuning, auto-focusing, with automatic chromatic aberration resolution and brightness adjustment, adjustable image contrast; equipped with

15" HD LCD monitor. wds 700 mobile phone bga rework station

Multifunctional user-friendly operating system
1. Adopt high-definition touch human-machine interface; two-in-one design of upper heating head and placement head; provide a variety of titanium alloy BGA air outlets that can be rotated 360 degrees, easy to install and replace.

2. The X, Y, R angles are fine-tuned with a micrometer, and the positioning is accurate, and the accuracy can reach ±0.01mm.

Superior security protection
With alarm function, the machine can alarm by itself after BGA welding.
Temperature abuse, the circuit can automatically power off, double over temperature
The protection.Temperature parameter is password protected to prevent any modification.

Simple operation panel



 Powerful universal clamp + 360° rotatable nozzle



 HD camera

High sensitivity MCGS touch screen

Automatic output and input optical alignment



update system

The latest WDS-720 is an update system with 5 modes. It is removal, installation, welding, manual and semi-automatic. The mode can be changed freely. It can be used in automatic, semi-automatic and manual modes. Car mobile repair tools
