lightweight mini mold repair portable laser welding machine

Supplier: Taizhou Shanda Mechanical & Electrical Technology Co., Ltd.
Region: Jiangsu, China
Contact: Ms. Victoria Xu
Price: $950.00 / 1 - 9 sets
$790.00 / >=10 sets
Min. Order: 1 set

Click here to contact

Product details

Single gross weight:	13.000 KG;	Voltage:	220v;
Core Components:	Engine;	Weight (KG):	9;
Pulse Width:	10/;	Dimensions:	370155320mm;
After-sales Service Provided:	Free spare parts,Video technical support,Online support;	Machine Type:	Welding Manipulator;
Key Selling Points:	Easy to Operate;	Place of Origin:	Jiangsu, China;
Warranty:	One Year,1 Year;	Usage:	precision welding;
Local Service Location:	None;	Certification:	CE;
Condition:	New;	Welding mode:	Spot/Continuous/Arc/Electro welding;
Function:	Welding or repairing steel;	Marketing Type:	Hot Product 2019;
Video outgoing-inspection:	Not Available;	Selling Units:	Single item;
After Warranty Service:	Video technical support;	Warranty of core components:	1 Year;
Frequency:	1-10HZ;	Spot welding diameter:	0.4-2.0mm;
Single package size:	47X37X36 cm;	Applicable Industries:	Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Retail,Construction works ,Other;
Showroom Location:	None;	Brand Name:	SHANDA;
Machinery Test Report:	Not Available;	Weight:	9kg;

lightweight mini mold repair portable laser welding machine

Product Description

Working Principle

Based on big power inverter technology (AC-DC-AC-DC),we could convert the input current into the DC power of low voltage and high current ,which is what we need for welding.

By using microcomputer technology,our could :

1)get precise control of welding time

2)make the electric energy act between tungsten electrode and workpiece, in the form of pulsed ARC

3)extremely high temperature ARC make solder wire and the workpiece(made of metal material)melt together

4)thus welding task completed

Technical Superiority

1)very fast heating speed and little heat when welding:our machine could finish the soldering of workpiece and solder wire in several milliseconds

2)to the base of workpiece ,the less heat, the less warming up for the material except for the welding spot thus no color change and annealing effect happen

3)because of the extremely concentration of output pulse energy,our machine could weld copper and aluminum,which is hard for many many welders

4)high strength of welding,applied to metallurgy welding.the welding area after welding could be done with after-treatment such as milling and filing

5)reasonable power allocation,controlled by microcomputer chip,different workpiece could get perfect power allocation

6)large range of adaptation for voltage:when voltage is changing in 20%,machine could still provide steady power to be working normally

7)convenient to connect to the electricity:equipmented with Quick connector connector

8)easy to carry:light and small

Technology Parameters

Machine model	SDHB-3
Input Power	AC220V 50/60HZ
Power	0-4000W
Max Pw	40kw
Output	1-200A
Frequency	1-10HZ
Welding model	spot welding/continuous welding/arc welding /electro welding
Range of welding wire	0.3-2.0mm
Weight	9kg
Size	370155320mm

Advantages

Welding precision:Our SDHB series imitate laser cold welding machine has reached the accuracy(0.1-2.0mm) of laser welding machine

Price:Our cold welding machine is far cheaper than laser welding machine

Welding operation:Our cold welding machine is easier to operate than laser welding machine.You don't need to waste time to learn professional welding skills or employ a welder

Welding functions:Our cold welding machine has more functions (spot/continuous/arc/resistance welding)

Application&Samples

Excellent heat control,no damage to the workpiece.

Complete metallurgical wld,later under a variety of processing.

Can be used with all types of fillers,dia.0.2mm-1.6mm.

Apply to all kinds of molds,dies,press dies,stainless parts,cast iron parts,aluminum parts,copper/brass/bronze parts.

Recommended Products

Machine Model	SDHB-2	SDHB-5
Input Power	AC220V 50HZ	AC220V 50HZ
Power	0-4000W	10-1600W
Max Pw	40KW	>40KW
Output	1-200A	1-500A
Frequency	1-10HZ	1-5HZ
Welding Mode	Spot/continuous/arc welding	Spot/continuous/resisitance welding
Range of Welding Wire	0.3-2.0mm	0.1-2.0mm
Weight	9kg	15.75kg
Size	370155320mm	185440320mm
Feature	Precision repair sheet welding machine	Color plate welding without discoloration on the back
