Number of poles: | 3 | stage: | 1 |
product name: | LS-General Motors | Supply capacity: | 100 pieces per day |
place of origin; place of origin: | Zhejiang, China | Main circuit rated current: | 150a |
model: | LS-General Motors | Packaging Details: | standard |
Features: | used to the air conditioner | payment terms: | T/T, Western Union |
Test amplifier: | 10000A | Certificate: | CE certification |
Connection system: | crimp connection | Cable standard: | 2.5mm2 4.0mm2 6.0mm2 |
Amplifier: | 6A to 150A | color: | white |
volt: | Maximum AC690V | Grundig: | silver point |
Main circuit rated voltage: | 690V | Power type: | air conditioner |
port: | Shanghai/Ningbo | brand: | LNP |
application
GMC (MC) AC contactor MC (same as LS) series AC contactors are suitable for making and breaking and frequent starting, and controlling AC motors in circuits with rated voltage 660VAC 50Hz or 60Hz and rated current 9A to 85A. Combined with auxiliary contact group, air delay device, mechanical interlock device, etc. to form a delay contactor, mechanical interlock contactor, delta delta starter, and combined with a thermal relay to form an electromagnetic starter.
model |
GMC-9 |
GMC-12 |
GMC-18 |
GMC-22 |
GMC-32 |
GMC-40 |
||
IEC-60947 AC1 Responsibilities |
20A |
20A |
25A |
32A |
50A |
60A |
||
UL AC3 Responsibilities |
200-240V |
2.5KW 11A |
3.5KW 13A |
4.5KW 18A |
5.5KW 22A |
7.5KW 32A |
11KW 40A |
|
380-440V |
4KW 9A |
5.5KW 12A |
7.5KW 18A |
11KW 22A |
15KW 32A |
18.5KW 40A |
||
500-550V |
4KW 7A |
7.5KW 12A |
7.5KW 13A |
15KW 22A |
18.5KW 28A |
22KW 32A |
||
690V |
4KW 5A |
7.5KW 9A |
7.5KW 9A |
15KW 18A |
18.5KW 21A |
22KW 25A |
||
continuous current (th) |
20A |
25A |
30A |
32A |
45A |
50A |
||
AC motor |
1P |
115V |
0.5 hp |
0.5HP |
1 HP |
2 hp |
2 hp |
3 hp |
230V |
1 HP |
2 hp |
3 hp |
3 hp |
5 hp |
5 hp |
||
3P |
200V |
2 hp |
3 hp |
5 hp |
7 hp |
7.5 hp |
10 hp |
|
230V |
2 hp |
3 hp |
5 hp |
7.5 hp |
10 hp |
10 hp |
||
460V |
5 hp |
7.5 hp |
10 hp |
10 hp |
20 hp |
25 hp |
||
575V |
7.5 hp |
10 hp |
15HP |
15HP |
20 hp |
25 hp |
||
panel mount |
Rails & Screws |
|||||||
Dimensions (mm) |
44x80x86.8 |
68x82x94.6 |
||||||
Installation size (mm) |
30~35x48~59 |
