Core components: | engine | Marketing Type: | Hot Products of 2022 |
Health status: | new | Weight (kg): | 1400 |
Origin: | China | Core component warranty: | 1 year |
Applicable industries: | Hotels, Clothing Stores, Building Materials Stores, Machinery Repair Shops, Manufacturing Plants, Food & Beverage Plants, Farms, Restaurants, Home Use, Retail, Food Stores, Printing Shops, Construction, Energy & Mining, Food & Beverage Stores, Other, Advertising company | color: | blue |
brand: | Jingxinlong | Warranty: | 1 year |
Video shipment inspection: | if | port: | Shanghai or Ningbo |
Showroom location: | not any | payment terms: | L/C, Western Union, D/P, D/A, T/T |
Package preview: | Mechanical test report: | if |
parameter | unit | CTD40 | CTD80 | CTD120 | CTD150 |
Carrying capacity | Kilogram | 400 | 800 | 1200 | 1500 |
Rated safe load | Kilogram | 300 | 700 | 1000 | 1200 |
net weight | Kilogram | 500 | 850 | 1200 | 1400 |
load center | mm | 400 | 400 | 500 | 500 |
Maximum Lifting Height | mm | 2200 | 2200 | 2200 | 2200 |
Fork length | mm | 750 | 750 | 1000 | 1000 |
Mast inclination (fore/aft) | ° | 6/6 | 6/6 | 6/6 | 6/6 |
Dimensions | mm | 1200*650*1750 | 1400*960*1750 | 1600*960*1750 | 1650*960*1750 |
Ground clearance | mm | 100 | 120 | 100 | 120 |
Front tire model material | solid rubber | 350*100 | 400*80 | 400*80 | 400*100 |
Rear tire model material | external rubber | 150*75 | 200*100 | 200*100 | 200*100 |
Lead-acid batteries | voltage/ah | 48V32AH | 48V32AH | 48V45AH | 48V58AH |
motor | kilowatt | 1.5 | 0.8 | 1.8 | 1.8 |
lift motor | kilowatt | 1.6 | 1.5 | 1.2 | 1.8 |
walking speed | kW/h | 5.0 | 5.0 | 5.0 | 5.0 |
steering type | deal with | deal with | deal with | deal with | |
brake form | disc brake | disc brake | electric brake | electric brake |
