Package preview: | Rated speed: | 100-500 rpm | |
Packaging Details: | carton | Pre-sale project design: | Yes |
port: | Shanghai Guangzhou Shenzhen | Generator type: | Three-phase AC permanent magnet |
Battery Type: | lithium ion | model: | SM-S1 |
Rated wind speed: | 10 m/s | Supply capacity: | 500 pieces per month |
Rated voltage: | 12V/24V/48V/96V/220V/380V | product name: | vertical wind power |
Origin: | Jiangsu, China | Blade material: | reinforced glass fiber |
brand: | Smarade | Key words: | home wind turbine |
color: | customer request | payment terms: | L/C, D/P, D/P, T/T, PayPal |
Output voltage (V): | 24V/48V/96V/110V/220V | application: | Wind Power System, Home |
rated power: | 500W-10KW | Output frequency: | 50Hz/60Hz |
Model | SX-500 | SX-800 | SX-1000 | SX-1500 | |||
rated power | 500W | 800W | 1000W | 1500W | |||
Maximum power | 510W | 815W | 1150W | 1600W | |||
Rated voltage | 12V/24V | 12V/24V | 12V/24V/48V | 24V/48V/96V | |||
start wind speed | 2.0m/s | 2.0m/s | 2.0m/s | 2.0m/s | |||
Rated wind speed | 11 m/s | 13 m/s | 13 m/s | 11 m/s | |||
Survival wind speed | 50 m/s | 50 m/s | 50 m/s | 50 m/s | |||
number of blades | 3 | 3 | 3 | 3 | |||
high wind | 0.75m | 0.8m | 1.0 meters | 1.2m | |||
Blade material | FRP | ||||||
generator type | Three-phase AC permanent magnet generator | ||||||
Magnetic steel material | NdFeB | ||||||
Control System | electromagnet | ||||||
Operating temperature | -40℃~80℃ | ||||||
Design life | 20 years |
Model | SX-2000 | SX-3000 | SX-5000 | SX-10000 | |||
rated power | 2000W | 3000W | 5000W | 10000W | |||
Maximum power | 2150W | 3200W | 5600W | 12000W | |||
Rated voltage | 48V/96V/120V | 96V/120V/220V | 96V/120V/220V/ 380V | 96V/120V/220V/ 380V | |||
start wind speed | 2.0m/s | 2.0m/s | 2.0m/s | 2.0m/s | |||
Rated wind speed | 11 m/s | 11 m/s | 11 m/s | 11 m/s | |||
Survival wind speed | 50 m/s | 50 m/s | 50 m/s | 50 m/s | |||
number of blades | 3 | 3 | 3 | 3 | |||
high wind | 1.5m | 1.8m | 2.1 meters | 3.6m | |||
Blade material | FRP | ||||||
generator type | Three-phase AC permanent magnet generator | ||||||
Magnetic steel material | NdFeB | ||||||
Control System | electromagnet | ||||||
Operating temperature | -40℃~80℃ | ||||||
Design life | 20 years |
