Total weight (kg): | 9500 | brand: | Huibang |
Wheelbase(mm): | 3200 | Health status: | new |
Supply capacity: | 1000 sets per month | Core components: | engine |
Core component warranty: | 1 year | Warranty: | 1 year |
Marketing Type: | Hot Products of 2022 | engine: | 4105 Supercharging |
Machine size: | 5800*2600*3200mm | Origin: | Shandong China |
Applicable industries: | Building material stores, manufacturing plants, retail, construction, energy and mining, other | Gearbox: | 280 separate type |
Video shipment inspection: | not available | Showroom location: | not any |
Mechanical test report: | not available | Dimensions (L*W*H): | 5800*2600*3200,5800*2600*3200mm |
Unique selling point: | high load moment | weight: | 9500 kg |
payment terms: | L/C, D/P, D/P, T/T | port: | Qingdao |
Packaging Details: | wooden box | strength: | 8500w |
Reduction ratio: | 1:140 |
Model | 3.6 cubic meters |
Machine size(mm) | 5800*2800*3200 |
Wheelbase (mm) | 3200 |
Total weight(kg) | 9500 |
engine | 4105 Supercharging |
Power(kw) | 85 |
Gearbox | 280 separate type |
Drive axle | wheel speed reduction bridge |
tire | 16/70-22.5R |
bucket capacity(m³) | 0.7 |
Drum capacity(m³) | ≥2.8 |
Reduction ratio | 1:140 |
Rotating speed | ≥15 laps/min |
reducer | BPF (import) |
