payment terms: | T/T, Western Union | color: | silver |
Material: | steel rope | type: | pack |
Packaging Details: | carton | product name: | cable clamp |
port: | Tianjin harbor | Certificate: | ISO9000 |
model: | BFS | Origin: | Hebei china |
application: | Telecom Cable Installation | Supply capacity: | 10000 pieces per week |
brand: | D pair |
Split handle
Used for pulling when conductor ends are not available
Pull type: light and straight. Rod won't bend round
Single-ply braided galvanized steel mesh with rod closure and offset flexible eyes
Choose a grip with a maximum rated capacity that meets or exceeds the maximum pull force of the cable puller.
Model | Cable diameter | Breaking load | Second | rice |
SG-075A | 18-25mm | 1130 kg | 127mm | 279mm |
SG-100A | 25-32mm | 1590 kg | 127mm | 279mm |
SG-125A | 32-37mm | 1810 kg | 152mm | 406mm |
SG-150A | 37-50mm | 1810 kg | 229mm | 432mm |
SG-200A | 50-63mm | 1810 kg | 254mm | 483mm |
SG-250A | 63-75mm | 1810 kg | 305mm | 508mm |
SG-300A | 75-88mm | 1810 kg | 305mm | 533mm |
SG-350A | 88-101mm | 1810 kg | 305mm | 559mm |
SG-400A | 101-114mm | 2180 kg | 305mm | 584mm |
SG-450A | 114-127mm | 2270 kg | 305mm | 610mm |
SG-500A | 127-152mm | 2360 kg | 305mm | 635mm |
SG-600A | 152-177mm | 2450 kg | 305mm | 660mm |
