port: | Shenzhen | Origin: | Guangdong, China |
Warranty time: | 1 year | color: | white |
brand: | Net Union | power supply: | DC 12V/1A |
Warranty: | 12 months / 1 year | type: | FTTx solution, ONU |
application: | FTTH FTTxFTTB network | Supply capacity: | 5000 pieces per day |
network: | Wired LAN, wifi | MOQ: | 50 |
Packaging Details: | carton | Function: | FTTH fiber to the home system |
use: | Fiber to the Home Fiber to the Home Fiber to the Home | payment terms: | Western Union, T/T, MoneyGram |
product name: | jepononu | Package: | Neutral packing |
model: | GM219-S | Certification: | CE RoHS FCC |
Model | GM219-S |
outbound port contains | 1GE+3FE+1 phone+1USB |
WIFI signal | support |
wireless gain | support |
USB | support |
local area network | 1*10/100/1000Mbps adaptive Ethernet port, full/half duplex, RJ45 interface |
Telephone | H248/Sip voice protocol |
PPPOE | support |
firmware | English |
size and weight | 116mm*136mm*28mm/145g |
Fiber port | 1 GPON/EPON/XPON interface, single fiber, downlink rate 2.5Gbps, uplink rate 1.25Gbps |
wavelength | Transmit 1310nm, Receive 1490nm |
fiber optic interface | SC/FC-UPC/APC Dual Mode/Single Mode |
Receiver sensitivity | >-28dBm (1490nm) |
DC power supply | 12V 1.0A, external AC-DC power adapter |
button | reset, power |
Operation | Working temperature: -5-+55℃ Working humidity: 10-90% (non-condensing) |
storage | Storage temperature: -30°C- +60°C Storage humidity: 10-90% (non-condensing) |
