Carton Box Making Machine Automatic Corrugated Cardboard Box Flexo Die Cutting Machine/Printing Machine/Carton Slotting Machine

Supplier: Cangzhou Longway Imp&Exp Co., Ltd.
Region: Hebei, China
Contact: Ms Andy Sun
Price: $15000.00 / 1 - 1 sets
$13000.00 / >=2 sets
Min. Order: 1 set

Click here to contact

Product details

Voltage:	380V/220V	brand:	Longway brand
color:	any color	Warranty:	1-2 years, 1 year
payment terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram	Applicable industries:	Hotels, Clothing Stores, Building Materials Stores, Manufacturing Plants, Machinery Repair Shops, Food and Beverage Plants, Farms, Restaurants, Home Use, Retail, Food Stores, Printing Shops, Construction, Energy and Mining, Food and Beverage Stores, Other, Advertising company
application:	Carton rotary die-cutting	Mechanical test report:	if
Materials used for packaging:	carton	Key words:	rotary die cutting
Origin:	Hebei china	Local service location:	not any
Driver type:	electrical	usage:	paper forming machine
Certification:	CE ISO9001	Packaging Details:	Pallet or wooden box
Marketing Type:	normal product	Main selling points:	easy to operate
Showroom location:	not any	port:	Tianjin
Box type:	Special standard carton	Health status:	new
product name:	Carton Rotary Die Cutting Machine, Corrugated Cardboard Die Cutting Machine	After warranty service:	Video technical support, online support
weight:	3000 kg	Core components:	engine, motor
Core component warranty:	1 year	raw material:	cast iron
Supply capacity:	5 sets per month	Dimensions (LWH):	240033001800mm
type:	semi-automatic or fully automatic	Video shipment inspection:	if
Automatic level:	automatic

Product Description

China Carton Making Machine Automatic Corrugated Board Carton Flexo Die Cutting Machine/Printing Machine/Carton Slotting Machine

Machine Features:

1. The machine wall is made of 60mm thick cast iron with good shock resistance to ensure stable transmission and accurate gear meshing. Finishing is processed by a high-precision machining center at one time to improve accuracy. Use an accurate spirit level to make adjustments when installing the machine.

2. All transmission shafts and rollers are made of high-quality steel, high-precision dynamic balance adjustment to ensure smooth transmission; all transmission shafts and rollers are polished and hard chrome-plated to ensure durability.

3. All transmission gears are made of high-quality low-carbon alloy steel (20CrMnTi), ground teeth, and the tooth width reaches 60mm.

4. The whole machine adopts non-adhesive connecting rings to eliminate gaps and is suitable for high-speed printing. And it is a key transmission component.

5. Spray circulation is used to lubricate the gears, two oil pumps supply oil in circulation, and the oil level is self-balancing. No need to drain oil and no oil leakage.

6. Electric separation and closing of the machine section. Pneumatic locking, automatic braking when separating, to ensure that the printing is not in place.

7. The alarm sounds continuously when the machine is moving to ensure the safety of workers.

8. The phase adjustment of printing department and die-cutting department is controlled by PLC and multi-function touch screen inverter. Easy to operate and control.
