110V/220V TIG WelderARC TIG 2 in 1 Welder140Amp Stick MMA IGBT Smart Inverter

Supplier: Guangdong Dibao Motor Co., Ltd.
Region: Guangdong, China
Contact: Ms Huang Sunny
Price: $123.00 / 1 - 9 pieces
$98.00 / 10 - 49 pieces
$92.00 / 50 - 99 pieces
$83.00 / >=100 pieces
Min. Order: 1 piece

Click here to contact

Product details

Tungsten needle diameter:	1.0MM-2.0MM	product name:	TIG-140I
technology:	Inverter IGBT Technology	Origin:	Guangdong, China
Motor type:	AC DC	aspect:	16148cm, 15.5113.667.87 inches
Weight (kg):	6.7 kg	Health status:	new
Rated output current (TIG):	200A	Accessories:	Ground clamp + electrode holder + TIG welding torch
Nominal Duty Cycle (TIG) at 40°C:	60%	Applicable industries:	Building materials store, welding
Main selling points:	easy to operate	Welding current/voltage range:	20-200 amps
Rated input capacity:	6KVA	Material/Metal Processing:	carbon steel, stainless steel
Rated input voltage:	50 volts	Video shipment inspection:	if
Package preview:		maximum. Load power capacity:	6KVA
Rated output voltage (TIG):	50 volts	usage:	weld metal
Mechanical test report:	if	color:	yellow+gray or OEM
feature:	stable and portable	brand:	Simd
Output polarity:	AC/DC TIG welding	Weldable plate thickness:	0.5MM-3MM
payment terms:	Western Union, D/P, T/T, MoneyGram	Pulse frequency:	50/60 Hz
type:	Argon arc welding	Warranty:	1 year

Product Description

Product overview

TIG welding machine 110V/220V ARC TIG two-in-one welding machine

140Amp Stick MMA IGBT Digital Smart Inverter TIG Welding Machine with TIG Welding Gun

* 【TIG & ARC Dual Function Welding Machine】The welding thickness is 0.5MM-3MM. Rods 7018, 6013, 6010 are suitable for stick welding. The tungsten electrode is suitable for 1.0MM-2.0MM. Suitable for stainless steel, alloy steel, carbon steel and other non-ferrous metal welding

*【Powerful and Portable TIG Welder】Excellent professional design TIG welding machine with excellent arc stability for thin workpieces. The lightness and strength of this tig/mma/arc/stick welder assembly make this a reliable welding tool for professional or personal use

* 【Advanced Technology MMA/Stick/Arc Welder】PWM (Pulse Width Modulation) adopts IGBT technology, which has high efficiency, fast welding speed, easy arc start and good arc stability

List of functions

1	Voltage:	110V/220V
2	frequency	50/60 Hz
3	Rated input capacity	6KVA
4	no-load voltage	56V
5	Output current adjustment	10-140A
6	Rated output voltage	25.6V
7	refueling time	1-5 seconds
8	load duration	35%
9	Load loss	45W
10	efficiency	85%
11	power factor	0.7
12	insulation level	f
13	Enclosure rating	IP21S

continuous argon arc welding

hHigh frequency spot welding

Instant arc welder

* Gas delay stepless control can be adjusted between 0.1-5 seconds; 0.1 seconds, suitable for spot welding and short welding

* Turn off argon gas at the end of welding, saving 40% gas

* Overheating and near-load protection to protect personal safety, energy saving, easy arc ignition

Double solar term non-stick electrodePortable and dual-useSmart Tig Mixed Martial Arts Stick

Tig Arc Welder Tig MMA WelderTIG welding machinearc welding

packing list:

* TIG-200I welding machine with 1.5m power cord
* TIG welding torch WP-17# with cable (4m/13ft)
* 300A electrode stand cable (2m/6.5ft)
* 300A with cable ground clamp (1.8m/5.9ft)
* 3 pieces to collect
* 1 collection
* 2 air nozzles
* 20cm conversion line

Thin plate is not easy to burn through

* The welding time controls the temperature, and the welding workpiece is welded by instantaneous current discharge
* The temperature of the soldering point is low and the deformation is small
* The longer the soldering time, the darker the solder joint color
*Real machine operation, no fraud

Suitable for these welds:

* Welding angle iron
* Stainless steel welded
* Added wire/spot welding
* Manual welding function

Manufacturing Technology
