Low cost CNC friction welding for drill pipe

Product details
payment terms:L/C, T/T, Alibaba credit guaranteeWeld diameter:8-20mm
Nominal Duty Cycle:100%Origin:Shandong China
Movement fixture clamping length:80-450mm or unlimitedusage:welding
Main motor:22 kWHealth status:new
Video shipment inspection:ifRotating speed:1500 rpm
Main selling points:automaticproduct name:Rotary Friction Welding Machine
Marketing Type:normal productport:Qingdao/Tianjin/Shanghai/Guangzhou/Shenzhen port, etc.
Weight (kg):6500 kgWelding materials:dissimilar metal
Mechanical test report:ifMaximum working stroke:300 mm
Core components:PLC, motortype:friction welding machine
Showroom location:Vietnam, MalaysiaCore component warranty:1 year
Maximum Thickening Force:100 kNApplicable industries:Mechanical repair shop, manufacturing plant
Oil pump motor:9.5 kWRotary fixture clamping length:50-200 mm
Supply capacity:100 sets per monthWarranty:1 year
Voltage:380VPackaging Details:1. 20ft/40ft Container(LCL) : packed in wooden case, then put into container 2, 20ft/40ft Container(FCL)

Product Description

1.1 Equipment name: single head friction welding machine

1.2 Equipment model: PFW-D2A

1.3 Introduction

This type of equipment is a high-precision single-head friction welding machine, and the whole machine is driven by full servo electric control (the welding upsetting process uses a servo motor to drive the ball screw to complete the welding);



The equipment is equipped with a weldment quality inspection system, which can detect welding process parameters in real time. When the equipment has parameter deviations, it will automatically alarm to reduce the occurrence of unqualified products. Users can copy the data and save it as internal testing data of the product. If necessary, the user can connect the printer to print the paper detection data report directly;



The equipment adopts the latest electronically controlled servo sliding table working system, which ensures the stable state of the equipment and avoids the hidden danger of instability in the hydraulic system;



Equipment composition: main machine mechanical part (electric brake servo spindle), electric drive servo slide table, hydraulic system (each clamping), lubrication system, electrical cabinet, a set of detection and control system;





summarize

Specification

brand



Mechanical part

Spindle bearing

Tapered roller

Germany FAG/Japan NSK

Linear Guides

heavy duty

Bank of Taiwan

Ball screw rod

heavy duty

Taiwan TBI

sealing element

Different kinds

Taiwan Ht





electrical



part

Programmable Controllers

S7-1200

Siemens

PLC processing module

Different kinds

Siemens

industrial computer

touch screen industrial computer

Taiwan Greetech

relay

RJ2S

Japan DigiKey

contactor, circuit breaker

Different kinds

Chint

Main switch group

XB5 series

Chint

industrial power

24v

Mean Well Taiwan

spindle drive

5 kW

Beijing Urban Management Bureau

Spindle motor

3.7 kW

Beijing Urban Management Bureau

sliding motor

2 kW

Beijing Urban Management Bureau



Electric slide

5 kW

Beijing Urban Management Bureau

hydraulic part

whole station



Taiwan Kings

Air conditioner



Taiwan Kings
